27 Limitations
27.1 C.i.e.
Max. number of "items":
Item
Max. no.
Fire alarms (presented in the EBL128
display as ZONE and/or ZONE-
ADDRESS)
168
256
Number of zones
99
Faults
200
External faults
50
Technical warnings
50
Short circuit isolators
64
Loop units
255
Trigger conditions (in all the control
expressions)
Approx.
1000
Interlocking Combinations
100
3377 + 3378 + 3379 + 4477 units
50
Total number of detectors and/or manual
call points
512
169
Max. number of AAF zones
50
Max. number of detectors per AAF zone
5
Max. number of I/O Matrix boards.
If no expansion boards.
4
4+4
Max. number of outputs per c.i.e. incl.
all kinds of outputs
200
Max. number of inputs
128
4380 units
10
168
Up to 256 ZONEs and/or ZONE-ADDRESSes can be programmed but
only the zone numbers 01-99 can be used.
169
Max. number of alarm points per c.i.e. (microprocessor) is 512 and max.
number of alarm points per zone is 32, i.e. if more than 12 conventional zone
line inputs are used, care must be taken in order not to exceed 512 detectors
and/or manual call points connected to the c.i.e. (12 x 32 = 384; 128 + 384 =
512).
