5-8
Code
Function Condition Message display
No.
76543210
14 a) LCC detecting sensor 1 LCC is not installed.
b) LCC door open/close sensor Door closed.
c) LCC detecting sensor 2 LCC is pulled out.
d) LCC paper tray lower limit Paper tray is beyond the
sensor lower limit.
e) LCC paper tray upper limit Paper tray is beyond the
sensor upper limit.
f) LCC paper level sensor Paper is full.
15 a) Corona cleaner home position Cleaner in home position.
sensor
b) Waste toner bottle full sensor Toner is full.
16,17
Not used
18 For FA-A505
a) Encoder sensor Signal is detected.
(When driving the transport belt)
b) Original detection sensor Original is detected.
c) Original feed pass sensor Original is detected.
d) Original exit pass sensor Original is detected.
e) ADF open/close sensor ADF is opened.
For FA-A888
a) Registration roller pass sensor Original is not detected.
b) Original reverse detection sensor Original is not detected.
c) Timing sensor Original is not detected.
d) ADF open/close sensor ADF is opened.
e) Entry cover open/close sensor Cover is closed.
f) Exit cover open/close sensor Cover is closed.
19 For FA-A888
a) Original size detection sensor Ledger/A3
Legal/B4-FLS
Letter/A4
Letter R/A4R
Invoice/A5
b) Original detection sensor Original is detected.
