1 Product overview
1.8 Specifications
The FP-I4C unit has the following characteristics and technical specifications.
Item Description
Product number AFP4C
Rated input voltage 24V DC, use the power supply cable (AFPG805) supplied with the unit
Operating voltage range 21.6–26.4V DC, supplied by class 2 circuit only
Serial interfaces COM1 RS232 (non-insulated), COM2 RS232/RS485 (insulated,
switchable)
16-pin spring force plug by Phoenix Contact Co. (MC0.5/8-ST-2,5)
Ethernet 2 Ethernet connectors, 10BASE-T/100BASE-TX auto-negotiation via
RJ45 female connector
USB 2 USB connectors, USB 2.0 full speed, max. 500mA (USB1), max.
100mA (USB2)
Function inputs 2 binary inputs (pull-up design) for optional functions
Operation status LEDs 7
Protocols and standards TCP/IP, UDP/IP, DHCP, FTP, FTPS, SSH, http, https, SMTP, ESMTP-
Auth, POP3, NTP, Modbus, DNS, SNMP, VPN, VNC, MQTT, SQL, OPC
UA
Flash memory 2.4GB user/configuration data
RAM 496MB
Current consumption ≈75mA at 24V DC (without expansion unit, USB flash memory, etc.)
Degree of protection IP20
Operating temperature 0°C to +55°C
Storage temperature -20°C to +70°C
Operating humidity 10%–95% RH (at 25°C, non-condensing)
Storage humidity 10%–95% RH (at 25°C, non-condensing)
Vibration resistance 10Hz to 55Hz, 1 cycle per minute with a double amplitude of 0.75mm;
10min on 3 axes
Shock resistance ≥10g, 4 times on 3 axes
Unit dimensions Height: 90mm, width: 25mm, depth: 64mm
Weight ≈110g
Operation conditions Free from corrosive gases and excessive dust
Conformity to CE
Directives
EMC Directive 89/336/EEC; EN 55022/Class B; EN 61000-4-2/A1; EN
61000-4-3; EN 61000-4-4 + A1:2010; EN 61000-4-6
UL approval UL number "2LD7" (file E232530)
14 FP-I4C
