Panasonic HM-TA2 - Preparation; Parts Identification and Handling

18 VQT3N87
Preparation
Parts identification and handling
1 Internal microphones
2 Power button [ ] (l 31)
3 Speaker
4 Hand strap fixture
≥
Attach the hand strap to this unit and adjust its length using the stylus pen.
5 Recording button (l 35)
6 Status indicator (l 22, 29, 31, 58)
7 LCD monitor (Touch screen) (l 32)
8
Screen lock button (l 41)
Due to limitations in LCD production technology, there may be some
tiny bright or dark spots on the LCD monitor screen. However, this is
not a malfunction and does not affect the recorded picture.
HM-TA20
HM-TA2
1
8
2
3
4
6
7
5
1
2
3
4
6
7
5



HM-TA20
