VQT3N87 29
Caution:
Check that the status indicator has gone off.
1 Open the SD card door and insert (remove) the SD
card into (from) the card slot B.
≥ Face the label side C in the direction shown in the illustration and
press it straight in as far as it will go.
≥ Press the center of the SD card and then pull it straight out.
≥
Open the SD card door after releasing the lock with the LOCK
lever for the SD card door.
2 Securely close the SD card door.
Inserting/removing an SD card
When using an SD card not from Panasonic, or one previously used
on other equipment, for the first time on this unit, format the SD card.
(l 57) When the SD card is formatted, all of the recorded data is
deleted. Once the data is deleted, it cannot be restored.
Status indicator A
≥ When this unit is accessing
the SD card, the status
indicator lights up.
≥ Insert SD card as shown in the figure.
HM-TA20
HM-TA20&TA2_P&PC-VQT3N87_mst.book 29 ページ ２０１１年４月２２日 金曜日 午後１２時１１分
