22 VQT3N87
Preparation
Charging the battery
Important:
≥ This unit has a built-in rechargeable lithium-ion battery. Do not
remove except when disposing of this unit.
≥ The battery will not be charged if the unit is turned on.
≥ The battery can also be charged using the AC adaptor (optional).
(l 23, 98)
1 Take out the USB terminal.
≥ Be careful as the USB terminal will jump out.
1 Slide the LOCK lever for the USB terminal cover A to release the
lock on the open/close lever for the USB terminal cover B.
2 Open the USB terminal cover while sliding the open/close lever for
the USB terminal cover B in the direction indicated by the arrow.
3 Press the USB Latch C until the USB terminal comes out.
1 Slide the USB Latch A until the USB terminal cover opens.
2 Slide the USB Latch A again until the USB terminal comes out.
When this unit is purchased, the battery is not charged. Charge
the battery fully before using this unit for the first time.
