USB Latch (l 22)
20 USB terminal [ ] (l 22, 65, 67, 73)
21 USB terminal cover (l 22)
22
HDMI cover
23
Headphone terminal cover
About locks for USB terminal cover, HDMI/Headphone cover and
SD card door
Each door/cover is equipped with a LOCK lever to lock the open/close
lever. When opening and closing the door/cover, slide the LOCK lever
and then slide the open/close lever.
USB terminal cover
HDMI/Headphone
cover
SD card door
A LOCK lever
B Open/close lever
HM-TA20
HM-TA2
HM-TA2
HM-TA20













