VQT4F67 27
5 Hand strap fixture
6 Zoom range button [ ] (l 77)
7 Photoshot button [ ] (l 55)
8 SET button [SET] (l 64, 68, 103, 114)
≥ Use the SET button to select the recording functions and playback
operations, and to operate the menu screen.
≥
In these operating instructions, the SET button is denoted as shown below.
Example:
9 In Recording Mode: Zoom lever [W/T] (l 76)
In Playback Mode: Volume lever (l 66, 121)
Zoom lever [W/T] (l 118)
Thumbnail display switch [ / ] (l 66)
10 Recording start/stop button [ ] (l 52)
11 Menu button [MENU] (l 68)
12 REC/ button [REC/ ]
(
l 47
)
13 Battery/Card cover (l 31, 42)
14 Battery holder
15 Card slot
or Select using the SET button
