Panasonic HX-DC2 - Names and Functions of Main Parts; Hx-Wa20;Hx-Wa2

VQT4F67 23
HX-WA20/HX-WA2
1 LCD monitor (l 51)
≥ It can open up to 90o A, rotate up to 180o B towards the lens or 105o
C towards the opposite direction.
2 Power button [ ] (l 44)
3 Status indicator (l 5, 33, 40, 190)
4 Open/close lever [SD CARD/BATTERY] (l 29, 40)
5 Lock lever [LOCK] (l 29, 40)
6 Menu button [MENU] (l 68)
7 REC/ button [REC/ ] (l 47)
8 Intelligent auto button [ ] (l 61)
Preparation
Names and Functions of Main Parts
Due to limitations in LCD production technology, there may be some
tiny bright or dark spots on the LCD monitor screen. However, this is
not a malfunction and does not affect the recorded picture.
12
8
3
7
6
4
5

