30 VQT4F67
2 (To insert the battery pack)
Confirm the orientation of the terminal markings and
insert the battery.
A terminal markings
≥ Confirm that lever B is locked on to the battery.
≥ It is possible to mistakenly insert the battery upside down, so be sure to
check the orientation carefully.
(To remove the battery pack)
Push the lever B toward the
direction of arrow, and pull the
battery straight out.
3 Close the rear door.
HX-WA20EB-VQT4F67_mst.book 30 ページ ２０１２年２月１３日 月曜日 午後３時５７分
To Next Page
