MEWTOCOL
command code
Data item Data
RD/WD DT00202 SV rise rate Set value, Decimal point ignored
RD/WD DT00204 SV fall rate Set value, Decimal point ignored
RD/WD DT00210 Control output OUT/OFF 0000H: Control output ON
0001H: Control output OFF
RD/WD DT00212 Auto/Manual control 0000H: Automatic control
0001H: Manual control
RD/WD DT00214 Manual control MV Set value
RD/WD DT00228 Alarm 1 Energized/Deenergized 0000H: Energized
0001H: Deenergized
RD/WD DT00230 Alarm 2 Energized/Deenergized 0000H: Energized
0001H: Deenergized
0000H: K -200 to 1370
0001H: K -200.0 to 400.0
0002H: J -200 to 1000
0003H: R 0 to 1760
0004H: S 0 to 1760
0005H: B 0 to 1820
0006H: E -200 to 800
0007H: T -200.0 to 400.0
0008H: N -200 to 1300
0009H: PL- 0 to 1390
000AH: C (W/Re5-26) 0 to 2315
000BH: Pt100 -200.0 to 850.0
000CH: JPt100 -200.0 to 500.0
000DH: Pt100 -200 to 850
000EH: JPt100 -200 to 500
000FH: K -320 to 2500
0010H: K -320.0 to 750.0
0011H: J -320 to 1800
0012H: R 0 to 3200
0013H: S 0 to 3200
0014H: B 0 to 3300
0015H: E -320 to 1500
0016H: T -320.0 to 750.0
0017H: N -320 to 2300
0018H: PL- 0 to 2500
0019H: C (W/Re5-26) 0 to 4200
001AH: Pt100 -320.0 to 1500.0
001BH: JPt100 -320.0 to 900.0
001CH: Pt100 -320 to 1500
001DH: JPt100 -320 to 900
RD/WD DT00236 Input type
001EH: 4 to 20mA -2000 to 10000
001FH: 0 to 20mA -2000 to 10000
0020H: 0 to 1V -2000 to 10000
0021H: 0 to 5V -2000 to 10000
0022H: 1 to 5V -2000 to 10000
0023H: 0 to 10V -2000 to 10000
RD/WD DT00238 Direct/Reverse action 0000H: Reverse action
0001H: Direct action
RD/WD DT00242 AT bias Set value
RD/WD DT00244 ARW Set value
RD/WD DT00246 Heater burnout alarm 2 value Set value, Decimal point ignored
