6.2 Outline for the Working of Power Monitoring Mode Display
It displays measured value as below with Power Monitoring Mode.
Integral electric power
Integral
active power
→
<SHIFT/
▽
>
Integral
reactive power
→
<SHIFT/
▽
>
Integral
apparent power
↓
<ITEM/
△
>
Instantaneous electric power
Instantaneous
active power
→
<SHIFT/
▽
>
Instantaneous
reactive power
→
<SHIFT/
▽
>
Instantaneous
apparent power
↓
<ITEM/
△
>
Current
L1 (CT1)
→
<SHIFT/
▽
>
L2 (CT2)
→
<SHIFT/
▽
>
L3 (CT3)
↓
<ITEM/
△
>
Voltage
L1 (P1-P0)
→
<SHIFT/
▽
>
L2 (P2-P0)
→
<SHIFT/
▽
>
L3 (P3-P0)
↓
<ITEM/
△
>
Electricity charge
↓
<ITEM/
△
>
Power factor
↓
<ITEM/
△
>
Frequency
↓
<ITEM/
△
>
Hour meter
Load ON-time
(ON-h)
→
<SHIFT/
▽
>
Load OFF-time
(OFF-h)
↓
<ITEM/
△
>
Demand
Demand
power
→
<SHIFT/
▽
>
Ratio of
estimated
demand
→
<SHIFT/
▽
>
Demand log
→
<SHIFT/
▽
>
Monthly max.
demand log
↓
<ITEM/
△
>
Counter
<ITEM/
△
>
