KW8M Eco-POWER METER
36
6.2.1 Integral Electric power
It displays the integral electric power.
Press <SHIFT/> to shift active power, reactive power, apparent power.
Integral active power
(kWh)
Integral reactive power
(kvarh)
Integral apparent power
(kVAh)
Integral electric power is measured and displayed from 0.00 to 9999999.9 (kWh/kvarh/kVAh).
The decimal point is changed automatically.
(After reaching the full-scale (9999999.9), the value reverts to 0.00 but continues to measure.)
How to reset the integral electric power (active/reactive/apparent)
Hold down <SET> and press <MODE> makes integral electric power clear.
(Active power, reactive power, apparent power is reset by each.)
Reset
<SET>
ON
OFF
<MODE>
ON
OFF
0.00 999999.99 1000000.0 9999999.9
[kWh]
Lighting
[kvarh]
Lighting
[kVAh]
Lighting
