Panasonic KW8M - Mode5

KW8M Eco-POWER METER
28
4.2.5 MODE5
(Mode for setting the year, month, day and time.)
Calendar timer setting mode CAL *Only AKW8111H
Mode defines the year, month, day and time.
・ Set year -> month -> date -> hour-> minute.
*Do not set the false date, or it might occur a malfunction.
Initialize memory of the main unit by “initialize memory of main unit” (MODE4) after this setting.
When it is not initialized, it may not display log data correctly.
MODE5 Setting flow chart
Monitor
↓
<MODE>
MODE 1 display
↓ <ITEM/△> 4 times
MODE 5 display
↓ <SET>
Calendar timer setting mode *Only AKW8111H
Set the present time using <ITEM/△>, <SHIFT/▽>, < >, < >, <SET>.
Calendar timer can be set the range of 2000, January 1
st
00:00 to 2099, December 31
st
23:59.
[00 y] Blinking
Set Year
[01 m] Blinking
Set Month
[01 d] Blinking
Set Day
[00 h] Blinking
Set Hour
[00 m] Blinking
Set Minute
↓ <SET>
Monitor
