KW8M Eco-POWER METER
54
7.3.2 Data Register List
(Common to AKW8 series)
Data
register
Name Unit Kind of data Range R/W
DT00050
Rate
0.01
Unsigned 16bit
0 to 9999
R/W
DT00060 CT type
Rated A
(rms)
Unsigned 16bit
5,50,100,250,400,600
R/W
DT00061
Unit for
Pulse output
－
Unsigned 32bit
1(0.001),10(0.01),100(0.1),
1000(1),10000(10),100000(100)
999
(Instantaneous electric power:
Values of DT00064, 00065)
777 (Ratio for current alarm:
Value of DT00069)
555 (Count value for output:
Values of DT00158,00159)
333 (Ratio and time for Stand-by alarm:
Value of DT00077,00078)
222 (
Threshold for demand alarm
Value of DT00205,00206)
R/W
DT00062
DT00063
Primary side current
value when CT 5A
1A
Unsigned 16bit
1 to 4000
R/W
DT00064
Alarm value
(Instantaneous active power)
0.01kW
Unsigned 32bit
0 to 99999999
R/W
DT00065
DT00066
VT ratio
0.01
Unsigned 16bit
100 to 9999
R/W
DT00067
Current threshold for
time measurement
0.1％
Unsigned 16bit
10 to 1000
R/W
DT00068 Cutoff current
0.1％
Unsigned 16bit
10 to 500
R/W
DT00069
Ratio for current alarm
0.1
％
Unsigned 16bit
10 to 1000
R/W
DT00070 Voltage range
－
Unsigned 16bit
1; 400V 2; 200V
R/W
DT00077
Ratio for stand-by current
0.1%
Unsigned 16bit
10 to 1000
R/W
DT00078
Time for stand-by alarm
1min.
Unsigned 16bit
0 to 9999
R/W
DT00100
Integral active power 0.01kWh
Unsigned 32bit
0 to 999999999
R/W
DT00101
DT00102
Integral
reactive power
0.01kvarh
Unsigned 32bit
0 to 999999999
R/W
DT00103
DT00104
Integral
apparent power
0.01kVAh
Unsigned 32bit
0 to 999999999
R/W
DT00105
DT00107
Current L1A(CT1)
0.1A
Unsigned 16bit
0 to 60000
R
DT00108
Current L2A(CT2)
0.1A
Unsigned 16bit
0 to 60000
R
DT00109
Current L3A(CT3)
0.1A
Unsigned 16bit
0 to 60000
R
DT00111
Power factor
0.01
Signed 16bit
-100 to 100
R
DT00112
Frequency
0.1Hz
Unsigned 16bit
0 to 1000
R
DT00150
Load ON-time 0.1h
Unsigned 32bit
0 to 999999
R/W
DT00151
DT00152
Load OFF-time 0.1h
Unsigned 32bit
0 to 999999
R/W
DT00153
DT00154
Pulse count value
－
Unsigned 32bit
0 to 99999999
R/W
DT00155
DT00158
Preset value
－
Unsigned 32bit
0 to 99999999
R/W
DT00159
DT00160
Prescale value 0.001
Unsigned 32bit
0 to 100000
R/W
DT00161
DT00162
Max. counting speed
Hz
Unsigned 16bit
30, 2000
R/W
DT00163
Auto-off time
min
Unsigned 16bit
0 to 99 (0:always on)
R/W
DT00170
Voltage L1V
(Between P1-P0)
0.1V
Unsigned 32bit
0 to 99999
R
DT00171
DT00172
Voltage L2V
(Between P2-P0)
0.1V
Unsigned 32bit
0 to 99999
R
DT00173
DT00174
Voltage L3V
(Between P3-P0)
0.1V
Unsigned 32bit
0 to 99999
R
DT00175
