KW8M Eco-POWER METER
55
Data
register
Name Unit
Kind of data
Range
R/W
DT00176
Instantaneous
active power
0.01kW
Unsigned 32bit
0 to 99999999
R
DT00177
DT00178
Instantaneous
reactive power
0.01kvar
Signed 32bit
-9999999 to 99999999
R
DT00179
DT00180
Instantaneous
apparent power
0.01kVA
Unsigned 32bit
0 to 99999999
R
DT00181
(Only for AKW8111H)
Data
register
Name Unit Kind of data Range R/W
DT00001
Contact output status
－
Unsigned 16bit
0;OFF, 1;ON
R
DT00048
Hysteresis for
demand alarm off
% Unsigned 16bit
0 to 100
R/W
DT00049
Demand monitor
start time
Minute Unsigned 16bit
1 to 30
R/W
DT20000
Log data
(Year/Month)
－
Unsigned 16bit
Higher word Lower word
Y: 00H to 99H M: 01H to 12H
R
DT20001
Log data
(Date/Hour)
－
Unsigned 16bit
Higher word Lower word
D: 01H to 31H H: 00H to 23H
R
DT20002
Log data
(Minute + Spare
）
－
Unsigned 16bit
Higher word
M: 00H to 59H
R
DT20003
Log data
Integral active power
0.01kWh
Unsigned 32bit
0 to 999999999
R
DT20004
DT20005
Log data
Integral reactive power
0.01kvarh
Unsigned 32bit
0 to 999999999
R
DT20006
DT20007
Log data
Integral apparent power
0.01kVAh
Unsigned 32bit
0 to 999999999
R
DT20008
DT20009
Log data
Voltage L1V
0.1V
Unsigned 32bit
0 to 99999
R
DT20010
DT20011
Log data
Voltage L2V
0.1V
Unsigned 32bit
0 to 99999
R
DT20012
DT20013
Log data
Voltage L3V
0.1V
Unsigned 32bit
0 to 99999
R
DT20014
DT20015
Log data
Current L1A(CT1)
0.1A
Unsigned 16bit
0 to 60000
R
DT20016
Log data
Current L2A(CT2)
0.1A
Unsigned 16bit
0 to 60000
R
DT20017
Log data
Current L3A(CT3)
0.1A
Unsigned 16bit
0 to 60000
R
DT20018
Log data
Pulse count value
－
Unsigned 32bit
0 to 99999999
R
DT20019
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
DT63180
Log data
(Year/Month)
－
Unsigned 16bit
Higher word Lower word
Y: 00H to 99H M: 01H to 12H
R
DT63181
Log data
(Date/Hour)
－
Unsigned 16bit
Higher word Lower word
D: 01H to 31H H: 00H to 23H
R
DT63182
Log data
(Minute + Spare）
－
Unsigned 16bit
Higher word
M: 00H to 59H
R
DT63183
Log data
Integral active power
0.01kWh
Unsigned 32bit
0 to 999999999
R
DT63184
DT63185
Log data
Integral reactive power
0.01kvarh
Unsigned 32bit
0 to 999999999
R
DT63186
DT63187
Log data
Integral apparent power
0.01kVAh
Unsigned 32bit
0 to 999999999
R
DT63188
