KW8M Eco-POWER METER
56
(Only for AKW8111H)
Data
register
Name Unit Kind of data Range R/W
DT63189
Log data
Voltage L1V
0.1V
Unsigned 32bit
0 to 99999
R
DT63190
DT63191
Log data
Voltage L2V
0.1V
Unsigned 32bit
0 to 99999
R
DT63192
DT63193
Log data
Voltage L3V
0.1V
Unsigned 32bit
0 to 99999
R
DT63194
DT63195
Log data
Current L1A(CT1)
0.1A
Unsigned 16bit
0 to 60000
R
DT63196
Log data
Current L2A(CT2)
0.1A
Unsigned 16bit
0 to 60000
R
DT63197
Log data
Current L3A(CT3)
0.1A
Unsigned 16bit
0 to 60000
R
DT63198
Log data
Pulse count value
－
Unsigned 32bit
0 to 99999999
R
DT63199
DT00071
Calendar timer monitor
(Hour/Minute)
－
Unsigned 16bit
Higher word Lower word
H: 00H to 23H M: 00H to 59H
R
DT00072
Calendar timer
(Minute/Second)
－
Unsigned 16bit
Higher word Lower word
M: 00H to 59H S: 00H to 59H
R/W
DT00073
Calendar timer
(Date/Hour)
－
Unsigned 16bit
Higher word Lower word
D: 01H to 31H H: 00H to 23H
R/W
DT00074
Calendar timer
(Year/Month)
－
Unsigned 16bit
Higher word Lower word
Y: 00H to 99H M: 01H to 12H
R/W
DT00075
Calendar timer
(Day)
－
Unsigned 16bit
Higher word
Day: 00H to 06H
R/W
DT00076 Logging cycle setting
－
Unsigned 16bit
6 types; 1(1),2(5),3(10),4(15),
5(30),6(60)
R/W
DT00080 SRAM Initialize
－
Unsigned 16bit
0;OFF 1;ON
R/W
DT00098
Integral active
power for arbitrary
period
0.01kWh
Unsigned 32bit
0 to 999999999
R/W
DT00099
DT00200
Present demand 0.01kW
Unsigned 32bit
0 to 99999999
R
DT00201
DT00203
Estimated demand 0.01kW
Unsigned 32bit
0 to 99999999
R
DT00204
DT00205
Demand setting value 0.01kW
Unsigned 32bit
0 to 99999999
R/W
DT00206
Note1) R: Read W: Write
2) Data register except specified is 0.
3) DT00061, 00062 (Unit for pulse output) is numerical value (in the range of data register).
4) If each setting value is wrote by communication, it memories to internal EEP-ROM at the same
time. Therefore, change setting frequently makes EEP-ROM’s life short. Avoid to usage like this.
5) Write a data within the range when you write it.
