7.3.3 Error Codes
◇Basic procedure errors
Error code
Error name
Explanation
40H Bcc error
・A Bcc error occurred in the command data.
41H Format error
・A command message was sent that does not fit the transmission
format.
42H No support error
・A command was sent that is not supported.
43H Procedure error
・Delimiter with multiple frames was sent.
・The response shall be multiple frames.
◇Application error
Error code
Error name
Explanation
60H Parameter error
・The data code is not “D”.
61H Data error
・Word No. is specified without decimal.（0000F etc.）
・The starting word No. is bigger than the ending word No.
・
Writing data has a code that is not hexadecimal.
62H Registration error
・Too many registrations have been entered (more than 17).
・“MD” command was sent when some registration has been exist.
・ “MG”
command was sent when registration has not been
entered.
◇Self-diagnostic error
Error code
Error name
Explanation
45H Operation error
・At “WD” command, writing data is exceeded the range of data
register.
7.3.4 Command
Eco-POWER METER has 5 kinds of commands.
Command name
Code
Explanation
Read data area
RD
Reads the contents of data area.
Write data to data area
WD
Writes data to a data area.
Resister or Reset data monitored
MD
Resisters the data to be monitored.
Monitoring start
MG
Monitors a registered data.
Read status
RT
Reads the specifications of Eco-POWER METER and error code
if an error occurs.
◆[RD]: Read data area (Reads the contents of data area.)
◇Command
％
×10
1
×10
0
＃
R D D
×10
4
×10
3
×10
2
×10
1
×10
0
×10
4
×10
3
×10
2
×10
1
×10
0
×16
1
×16
0
CR
◇Normal response (Read successful)
％
×10
1
×10
0
$ R D
×16
1
×16
0
×16
3
×16
2
×16
1
×16
0
×16
3
×16
2
×16
1
×16
0
CR
◇Error response
％
×10
1
×10
0
！
×16
1
×16
0
×16
1
×16
0
CR (Common to each command)
◆[WD]: Write data area (Writes date to a data area.)
◇Command
％
×10
1
×10
0
＃
W D D
×10
4
×10
3
×10
2
×10
1
×10
0
×10
4
×10
3
×10
2
×10
1
×10
0
×16
1
×16
0
×16
3
×16
2
⇒
◇Normal response (Write successful)
％
×10
1
×10
0
＄
W D
×16
1
×16
0
CR
⇒
×16
1
×16
0
×16
3
×16
2
×16
1
×16
0
CR
Starting word No.
5 characters
Ending word No.
5 characters
Bcc
Source
First register contents
4 characters
Last register contents
4 characters
Bcc
(lower word) (higher word)
Destination
Source
Error code
Bcc
Source
Starting word No.
5 characters
Ending word No.
5 characters
Destination
Bcc
First writing data
4 characters
Last writing data
4 characters
Bcc
(lower word) (higher word)
(lower word) (higher word)
(lower word) (higher word)
