KX-FLB802CX/KX-FLB812CX/KX-FLB802CXS/KX-FLB812CXS
19.2.1.18. TRAY SECTION (KX-FLB802
ONLY)
19.2.2. HANDSET CRADLE SECTION
19.2.3. ACCESSORIES AND PACKING
MATERIALS
• KX-FLB802
• KX-FLB812
19.2.4. DIGITAL BOARD PARTS
Ref.
No.
Part No. Part Name & Description Remarks
620 PFKS1134Z1 TRAY PS-HB
621 PFKS1132Z1 TRAY PS-HB
622 PFKS1133Z1 TRAY PS-HB
Ref.
No.
Part No. Part Name & Description Remarks
640 PFKF1085Y1 CABINET COVER S
641 PFBH1032Z1 PUSH BUTTON S
642 PFJA06B002Z CORD
643 PFKM1181X1 CABINET BODY S
Ref.
No.
Part No. Part Name & Description Remarks
A1 PFQW2446Z INSTRUCTION BOOK
A2 PFKS1117Y1 TRAY S
A3 PFJKFLB851Z MEMORY PARTS
A4 PFQX2364Z INSTRUCTION BOOK
A5 PFQW2403Z INSTRUCTION BOOK
A6 PFJA03A010Z POWER CORD (KX-FLB802CX)
A6 K2CT3EH00005 POWER CORD (KX-FLB802CXS)
A7 PFJA02B002Y CORD
A8 NOT USED
A9 PFJXE1041Z HANDSET
A10 PFJA1029Z CORD
A11 PFQW2404Z INSTRUCTION BOOK (KX-
FLB802CX)
A12 PFQW2405Z INSTRUCTION BOOK (KX-
FLB802CX)
A13 PFQW2402Z INSTRUCTION BOOK
P1 PFPK3051Z-M PACKING CASE (KX-FLB802CX) S
P1 PFPK3147Z-M PACKING CASE (KX-FLB802CXS) S
P2 PFPN1418Z CUSHION
P3 PFPN1419Z CUSHION
P4 PFPP1041Z PROTECTION COVER
P5 PFPN1416Z CUSHION
P6 XZB32X45A04 PROTECTION COVER
P7 PFPD1306Z CUSHION
P8 XZB20X35A04 PROTECTION COVER
P9 PFPN1417Z CUSHION
P10 PFPB1001Z CUSHION
P11 PFPD1309Z CUSHION
P12 PFPH1046Z PROTECTION COVER
P13 XZB20X30A04 PROTECTION COVER
Ref.
No.
Part No. Part Name & Description Remarks
B1 PFQW2447Z INSTRUCTION BOOK
B2 PFKS1117Y1 TRAY S
B3 PFJKFLB851Z MEMORY PARTS
B4 PFQX2364Z INSTRUCTION BOOK (KX-
FLB812CX)
B5 PFQW2403Z INSTRUCTION BOOK
B6 PFJA03A010Z POWER CORD (KX-FLB812CX)
B6 K2CT3EH00005 POWER CORD (KX-FLB812CXS)
B7 PFJA02B002Y CORD
B8 PFZXFLB811M TRAY
B9 PFJXE1041Z HANDSET
B10 PFJA1029Z CORD
B11 PFQW2404Z INSTRUCTION BOOK(KX-FLB812CX)
B12 PFQW2405Z INSTRUCTION BOOK(KX-FLB812CX)
B13 PFQW2402Z INSTRUCTION BOOK
K1 PFPK3053Z-M PACKING CASE (KX-FLB812CX) S
K1 PFPK3153Z-M PACKING CASE (KX-FLB812CXS)
K2 PFPN1418Z CUSHION
K3 PFPN1419Z CUSHION
K4 PFPP1041Z PROTECTION COVER
K5 PFPN1416Z CUSHION
K6 XZB32X45A04 PROTECTION COVER
K7 PFPD1306Z CUSHION
K8 XZB20X35A04 PROTECTION COVER
K9 PFPN1417Z CUSHION
K10 PFPB1001Z CUSHION
K11 PFPD1309Z CUSHION
K12 PFPH1046Z PROTECTION COVER
K13 XZB20X30A04 PROTECTION COVER
Ref.
No.
Part No. Part Name & Description Remarks
PCB1 PFWP1LB802CX DIGITAL BOARD ASS'Y (RTL)
(KXFLB802CX / 802CXS)
PCB1 PFWP1LB812CX DIGITAL BOARD ASS'Y (RTL)
(KX-FLB812CX / 812CXS)
(IC)
IC600 C1ZBZ0002831 IC
IC601 C3ABRG000037 IC S
IC602 PFWILB802CX1 IC (ROM)(KX-FLB802CX /802CXS)
IC602 PFWILB812CX1 IC (ROM)(KX-FLB812CX /812CXS)
IC603 C0CBADD00010 IC
IC604 C1ZBZ0002767 IC
IC605 C0DBAFF00019 IC
IC606 C0EBE0000124 IC
IC607 C5CB00000057 IC
IC608 C1CB00001985 IC
IC609 C1BB00000129 IC
IC610 C0JBAA000362 IC
IC611 C0JBAA000244 IC
IC612 C1DB00001173 IC
IC613 C0JBAA000362 IC
IC614 C0JBAA000362 IC
(TRANSISTORS)
Q600 B1ABDF000025 TRANSISTOR(SI)
Q601 2SB1197KQ TRANSISTOR(SI) S
Q602 2SB1197KQ TRANSISTOR(SI) S
Q603 PQVTD143Z106 TRANSISTOR(SI) S
Q604 PQVTD143Z106 TRANSISTOR(SI) S
Q605 PQVTD143Z106 TRANSISTOR(SI) S
Q606 PQVTD143Z106 TRANSISTOR(SI) S
Q607 2SB1197KQ TRANSISTOR(SI) S
Q608 2SB1197KQ TRANSISTOR(SI) S
Q609 PQVTD143Z106 TRANSISTOR(SI) S
Q610 2SD1820A TRANSISTOR(SI)
Q611 PQVTD143Z106 TRANSISTOR(SI) S
Q612 2SD1820A TRANSISTOR(SI)
Q613 2SB1197KQ TRANSISTOR(SI) S
Q614 PQVTD143Z106 TRANSISTOR(SI) S
Q615 PQVTDTA143ZU TRANSISTOR(SI) S
Q619 PQVTDTA143ZU TRANSISTOR(SI) S
Q620 PQVTD143Z106 TRANSISTOR(SI) S
Q621 2SB1197KQ TRANSISTOR(SI) S
Q622 PQVTD143Z106 TRANSISTOR(SI) S
Q623 2SD1820A TRANSISTOR(SI)
Q624 2SB1197KQ TRANSISTOR(SI) S
Q625 PQVTD143Z106 TRANSISTOR(SI) S
Q626 PQVTD143Z106 TRANSISTOR(SI) S
Q631 PQVTD143Z106 TRANSISTOR(SI) S
Q632 PQVTD143Z106 TRANSISTOR(SI) S
Q633 B1CHND000004 TRANSISTOR(SI)
Q634 PQVTD143Z106 TRANSISTOR(SI) S
Q635 PQVTD143Z106 TRANSISTOR(SI) S
Ref.
No.
Part No. Part Name & Description Remarks
