Panasonic KX-FP215

210
KX-FP215
20.2.4. Operation Board Parts
(PHOTO ELECTRIC TRANSDUC-
ERS)
PC103 0N3181 PHOTO COUPLER S
PC104 0N3131SKU PHOTO COUPLER S
(THERMISTOR)
POS101 PFRT002 THERMISTOR S
(RELAY)
RLY101 K6B1CYY00005 RELAY
(VARISTORS)
SA101 PFRZRA311P6T VARISTOR (Surge Absorber) S
SA102 PFRZRA102P6T VARISTOR (Surge Absorber) S
(TRANSFORMER)
T101 G4AYA0000016 TRANSFORMER
(RESISTORS)
L101 ERJ3GEY0R00 0
L102 ERJ3GEY0R00 0
L103 ERJ3GEY0R00 0
R101 ERJ3GEYJ222 2.2k
R102 ERJ3GEYJ103 10k
R103 ERJ3GEYJ682 6.8k
R104 ERJ3GEYJ433 43k
R106 ERJ3GEYJ433 43k
R107 ERJ3GEYJ220 22
R109 ERJ3GEYJ223 22k
R110 ERJ3GEY0R00 0
R111 ERJ3GEYJ124 120k
R112 ERJ3GEYJ223 22k
R113 ERJ3GEYJ113 11k
R120 ERDS2TJ331 330 S
R132 ERJ3GEYJ222 2.2k
R135 ERJ3GEYJ273 27k
R136 ERJ3GEYJ394 390k
R138 ERDS1TJ123 12k S
R140 ERJ3GEYJ394 390k
R143 ERJ3GEYJ472 4.7k
R144 PQ4R10XJ332 3.3k S
R145 ERJ3GEYJ154 150k
R146 ERJ3GEYJ105 1M
R147 ERJ3GEY0R00 0
R148 ERJ3GEYJ473 47k
R149 ERJ3GEYJ331 330
R150 ERDS1TJ473 47k S
R151 ERJ3GEYJ153 15k
R152 ERJ3GEYJ153 15k
R153 ERJ3GEYJ333 33k
R155 ERJ3GEYJ684 680k
R157 PQ4R10XJ822 8.2k S
R158 ERJ3GEYJ152 1.5k
R160 ERJ3GEYJ152 1.5k
R161 ERJ3GEYJ331 330
R167 ERG2SJ151 150
(CAPACITORS)
C102 ECEA0JKA470 47
C104 ECJ1VF1E104Z 0.1
C105 ECJ1VB1H391K 390P
C107 ECEA0JKA470 47
C109 ECJ1VB1H122K 0.0012
C110 ECJ1VB1C104K 0.1
C112 ECJ1VB1E273K 0.027
C113 ECJ1VB1C104K 0.1
C117 ECEA1HKA4R7 4.7
C118 ECUX1H103KBV 0.01 S
C127 ECJ1VB1H221K 220P
C128 ECEA1HN010S 1 S
C137 ECUX1H472KBV 0.0047 S
Safe
ty
Ref.
No.
Part No. Part Name & Description Remar
ks
C138 F0C2E105A216 1
C139 ECJ1VB1C473K 0.047
C141 F2A1E3300024 33
C142 ECJ1VB1C473K 0.047
C143 F2A1E4700025 47
C145 ECEA0JKA470 47
C146 ECUX1H103KBV 0.01 S
C149 ECEA0JKA470 47
C150 ECUX1H103KBV 0.01 S
C151 ECUX1H103KBV 0.01 S
Safe
ty
Ref.
No.
Part No. Part Name & Description Remar
ks
PCB3 PFWP2FP215C OPERATION BOARD ASS'Y
(RTL)
(IC)
IC301 C1ZBZ0003876 IC
(DIODE)
LED301 B3AAA0000534 LED
(LIQUID CRYSTAL DISPLAY)
CN302 L5DAAFB00001 LIQUID CRYSTAL DISPLAY S
(CONNECTOR)
CN301 K1KA08B00243 CONNECTOR, 8 PIN
(SENSOR SWITCHES)
E30 K0L1BA000126 SWITCH, SENSOR LEVER
E31 K0L1BA000127 SWITCH, SENSOR LEVER
(SWITCHES)
SW301 K0H1BA000259 SPECIAL SWITCH
SW302 K0H1BA000259 SPECIAL SWITCH
SW303 K0H1BA000259 SPECIAL SWITCH
SW304 K0H1BA000259 SPECIAL SWITCH
SW305 K0H1BA000259 SPECIAL SWITCH
SW306 K0H1BA000259 SPECIAL SWITCH
SW307 K0H1BA000259 SPECIAL SWITCH
SW308 K0H1BA000259 SPECIAL SWITCH
SW309 K0H1BA000259 SPECIAL SWITCH
SW310 K0H1BA000259 SPECIAL SWITCH
SW311 K0H1BA000259 SPECIAL SWITCH
SW312 K0H1BA000259 SPECIAL SWITCH
SW313 K0H1BA000259 SPECIAL SWITCH
SW314 K0H1BA000259 SPECIAL SWITCH
SW315 K0H1BA000259 SPECIAL SWITCH
SW316 K0H1BA000259 SPECIAL SWITCH
SW317 K0H1BA000259 SPECIAL SWITCH
SW318 K0H1BA000259 SPECIAL SWITCH
SW319 K0H1BA000259 SPECIAL SWITCH
SW320 K0H1BA000259 SPECIAL SWITCH
SW321 K0H1BA000259 SPECIAL SWITCH
SW322 K0H1BA000259 SPECIAL SWITCH
SW323 K0H1BA000259 SPECIAL SWITCH
SW324 K0H1BA000259 SPECIAL SWITCH
SW325 K0H1BA000259 SPECIAL SWITCH
SW326 K0H1BA000259 SPECIAL SWITCH
SW327 K0H1BA000259 SPECIAL SWITCH
SW328 K0H1BA000259 SPECIAL SWITCH
SW329 K0H1BA000259 SPECIAL SWITCH
SW330 K0H1BA000259 SPECIAL SWITCH
SW331 K0H1BA000259 SPECIAL SWITCH
SW332 K0H1BA000259 SPECIAL SWITCH
SW333 K0H1BA000259 SPECIAL SWITCH
SW334 K0H1BA000259 SPECIAL SWITCH
(RESISTORS)
R300 ERJ3GEYJ680 68
Safe
ty
Ref.
No.
Part No. Part Name & Description Remar
ks
