Panasonic KX-FP215

58
KX-FP215
10 Test Mode
The codes listed below can be used to perform simple checks for some of the unit’s functions. When complaints are received
from customers, they provide an effective tool for identifying the locations and causes of malfunctions. To do this, you set the
Service mode (Refer to Operation Flow (P.62).) first, then operate the below test items.
Test Mode Type of Mode Code Function
Operation after code
input
MEMORY CLEAR Service Mode “5” “5” “0” Refer to Memory Clear Specification (P.65).
SET
FLASH MEMORY
CHECK
Service Mode “5” “5” “1” Indicates the version and checks the sum of the FLASH MEMORY.
SET
DTMF SINGLE TEST Service Mode “5” “5” “2” Outputs the DTMF as single tones. Used to check the frequencies of the individ-
ual DTMF tones. Refer to DTMF Signal Tone Transmit Selection (P.59).
1....ON
2....OFF
MODEM TEST Service Mode “5” “5” “4” Telephone line circuit is connected automatically, output the following signals on
the circuit line.
1) OFF 2) 14400bps 3) 12000bps 4) 96V17 5) 72V17
6) 9600bps 7) 7200bps 8) 4800bps 9) 2400bps 9) 300bps 10) 2100Hz
8)1100Hz
SET
SCAN CHECK Service Mode “5” “5” “5” Turns on the LEDs of the CIS and operates the read systems.
-----
MOTOR TEST Service Mode “5” “5” “6” Rotates the transmission and reception motor to check the operation of the
motor.
00: Stop
02: TX
05: Pickup
08: Rx
10: Copy
11: Assist
13: Home position
• Press [STOP] button to quit.
SET
LED CHECK Service Mode “5” “5” “7” All LEDs above the operation panel board flash on and off, or are illuminated.
-----
LCD CHECK Service Mode “5” “5” “8” Checks the LCD indication.
Illuminates all the dots to check if they are normal.
SET
KEY CHECK Service Mode “5” “6” “1” Checks the key operation. (Except "STOP" key)
Indicates the button code on the LCD while the button is pressed. Refer to But-
ton Code Table (P.60).
The available key is
any one that except
[STOP] key.
MEMORY CLEAR
(except History data)
Service Mode “7” “1” “0” Refer to Memory Clear Specification (P.65).
SET
VOICE PROMPT
CHECK
Service Mode “7” “8” “4” You can hear the voice prompt from speaker after pressing [SET] key.
SET
