1. Introduction and Installation
14
For Fax Advantage assistance, call 1-800-435-7329.
L Make sure that the ink film is wrapped
around the blue core (3) at least once.
6 First close the back cover securely (1) by
pushing down on the dotted area on both
sides (2). Then close the front cover
securely (3).
1.8.2 Replacing the ink film
The included film roll is a complimentary starter
ink film. To ensure that the unit operates
properly, we recommend the use of Panasonic
replacement film. See page 9 for accessory
information.
L We cannot be responsible for any damage to
the unit or degradation of print quality which
may occur from the use of non-Panasonic
replacement film.
1 Open the covers (see steps 1 to 3 on page
13).
2 Pull out the blue gear (1) and remove the
used ink film (2). Remove the used core
(3).
3 Remove the stoppers (1) and tags (2) from
the new ink film (3).
4 Insert the ink film and close the covers (see
steps 4 to 6 on page 13).
Slack/Crease
Reverse
Correct
Incorrect
Tight
1 turn
The ink film is not wrapped
around the blue core.
3
2
1
3
1
2
3
1
1
3
2
0519_FPG381.book Page 14 Monday, May 19, 2003 6:46 PM
