10. Help
89
For Fax Advantage assistance, call 1-800-435-7329.
5 Turn the gear of the blue core (1) in the
direction of the arrow until the white core (2)
begins to turn.
L Make sure that the ink film is wrapped
around the blue core (3) at least once.
6 First close the back cover securely (1) by
pushing down on the dotted area on both
sides (2). Then close the front cover
securely (3).
7 Remove the recording paper and straighten.
Pull the tension plate forward (1) and insert
the paper. Then push the tension plate back.
10.4.2 When the recording paper
was not fed into the unit properly
The display will show the following.
CHECK PAPER
Remove the recording paper and straighten. Pull
the tension plate forward (1) and insert the
1
2
Slack/Crease
Reverse
Correct
Incorrect
Tight
1 turn
The ink film is not wrapped
around the blue core.
3
1
3
2
1
0519_FPG381.book Page 89 Monday, May 19, 2003 6:46 PM
