Panasonic KX-NS500 Sales Guide

Cost Saving
IP Networking -Saving Network Costs-
Features and Benefits
Recommended for:
Companies which have branches.
Companies using an IP network system.
Ext.2000 …
Dials [2999]
Ext.2999
Ext.3000 … Ext.3999
Ext.1000 … Ext.1999
IP
Networking
21
Save on call costs.
The PBX extension functions can be used
across multiple offices.
VoIP allows you to talk with your remote offices anywhere in the world without telephone charges using a private IP network.
KX-NS500
KX-NS500 KX-NS500

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
