1.2 Network Devices and Numbering Plan
Getting Started 11
PBX Connection Information
PBX connection information is created by combining IP Addressing Information and PBX
Numbering Information. Referring to the sample below, create your own PBX connection
information.
Leading Number:
A number composed of the PBX code followed by the first
digit of the destination number. See the example on the
right.
Remaining Digits:
The maximum number of digits to be dialed following the
leading number to access the destination. (However, for
example, setting the remaining digits to 7 does not mean
that the user must dial all 7 digits when making a call.)
See the example on the right.
Card IP Address:
The IP address of each card in the network (as the access destination).
Los Angeles Office (PBX Code: 35) Chicago Office (PBX Code: 41)
Extensions FAX
Extensions
PSTN
Access
Extensions FAX
Extensions
PSTN
Access
Leading
Number
352 355 359 413 416 419
Remaining
Digits
227227
Card IP
Address
200.45.11.35 199.176.64.41
352+00 to 99
PBX Code
Remaining DigitsLeading No.
Los Angeles extensions
First digit of
the extension
number
Remaining digits
of the extension
number
