1.2 Network Devices and Numbering Plan
12 Getting Started
1.2.3 Numbering Plan Summary
Reproduce this page and write down your network information in the space provided below for
each card in the network. Consult your network administrator to fill in the shaded entries.
PSTN
(Public Switched
Telephone Network)
IP Network
PBX Code:
PSTN Trunk (CO Line) Number:
TIE Line Access Number:
Extension Number:
Local Telephone:
G3 Fax Extension Number:
Subnet Mask:
IP Address
Card IP Address
Default Gateway IP Address
Subnet Mask Address
PBX Numbering
PBX Code
TIE Line Access Number
PSTN Trunk (CO Line) Number
Extension Number
Fax Extension Number
Card IP Address
Extensions
Leading Number
Remaining Digits
PBX Connection
PSTN AccessFax Extensions
Default Gateway IP:
Card IP:
