To remove a card from the PBX
1. Move the mouse pointer over the card to remove.
A menu will be shown under the mouse pointer.
2. Select Delete.
3. Click Yes to confirm.
The card will be removed.
To change the status (INS/OUS) of a card (Interactive mode only)
1. Move the mouse pointer over the card.
A menu will be shown under the mouse pointer.
2. Select the desired status:
• Click INS to set the card to in-service status.
• Click OUS to set the card to out-of-service status.
To install an option card on an OPB3 card
1. Move the mouse pointer over the card.
A menu will be shown under the mouse pointer.
2. Select Option Card.
The OPB3 Option Card Setup screen will be displayed. See 3.60 [1-1] Slot—OPB3 Option Card
Setup.
To access IP-PT port properties
1. Click the IP Phone Registration button.
Supported Card Types
KX-TDE100/KX-TDE200
Card Maximum Quantity Card Programming
IPCMPR: IP Convergence Main
Processing Card
1 (fixed in Slot 00)
3.4 [1-1] Slot—Card Property -
IPCMPR
PC Programming Manual 105
3.1 [1-1] Slot
