9.3. Disassembly Procedure
No. Item Fig. Removal
1 Rear Case Unit
(With LCD Unit)
(Fig. D1) Screw (A) 6
Screw (B) 1
Screw (C) 1
Locking tab 5
FP9003 (Flex)
Jack Cover Unit
Rear Case Unit (With LCD
Unit)
2 Rear Operation P.C.B.
Unit
(Fig. D2) Locking tab 1
FP9006 (Flex)
Rear Operation FPC
Rear Operation P.C.B.
Unit
3 Frame Plate (Fig. D3) Screw (D) 1
Locking tab (A) 1
Battery Lock Spring
Battery Lock Knob
Frame Plate
4 Main P.C.B.,
Speaker
(Fig. D4) Locking tab 2
Speaker Plate Unit
FP9001 (Flex)
FP9002 (Flex)
FP9004 (Flex)
FP9008 (Flex)
FP9009 (Flex)
FP9010 (Flex)
FP9011 (Flex)
FP9050 (Flex)
FP9051 (Flex)
Screw (E) 3
Main P.C.B
(Fig. D5) Note: (When replacing
Main P.C.B.) Heat
Radiation
Sheet, CU Protection
Sheet
(Fig. D6) Solder (2 points)
Speaker
5 Eye Sensor FPC (Fig. D7) Positioning boss 2
Hooking part 3
Eye Sensor FPC
6 Lens Unit (Fig. D8) Screw (F) 3
Lens Fix Plate
Lens Unit
7 Top Case Unit (Fig. D9) Screw (G) 1
Locking tab 2
Top Case Unit
8 LVF Unit,
Top P.C.B. Unit,
Flash Unit
(Fig. D10) Screw (H) 4
Locking tab (A) 1
LVF Unit
Top P.C.B. Unit
MIC Holder
MIC Spacer
MIC Unit
MIC Damper
Mode Plate
Locking tab (B) 2
AF Panel Light
Flash Spacer
Earth Spring
Solder A (3 points)
E. Capacitor
Solder B (3 points)
Flash Unit
Top Earth Plate
Top Earth Plate B
Wi-Fi FPC
Top FPC
(Fig. D11) Note: (When replacing
Top P.C.B. Unit, LVF Unit)
(Fig. D12) Note: (Precautions
concerning handling of
Top P.C.B. Unit)
9PCB Spacer,
Front Case Unit,
Control Ring Unit
(Fig. D13) Hooking part 2
PCB Spacer
Screw (I) 1
Locking tab 1
Front Case Unit
Screw (J) 3
Control Ring Unit
10 Battery Door Unit (Fig. D14) Battery Door Shaft
Battery Door Spring
Battery Door Unit
11 Strap Cover (R),
Strap Plate (R),
Front Earth Plate
(Fig. D15) Screw (K) 1
Locking tab (A) 1
Locking tab (B) 1
Strap Cover (R)
Locking tab (C) 1
Hooking part 2
Positioning boss 2
Strap Plate (R)
Front Earth Plate
12 Battery P.C.B.,
Strap Cover (L),
Strap Plate (L)
(Fig. D16) Screw (L) 1
Battery FPC
Hooking part 1
Battery P.C.B
Locking tab (A) 1
Locking tab (B) 2
Strap Cover (L)
Strap Plate (L)
13 Battery Case (Fig. D17) Locking tab 4
Battery Case
Gasket
14 LCD Unit (Fig. D18) Screw (M) 1
Screw (N) 2
Locking tab 1
Hooking part 1
Positioning boss 2
Hinge Cover
LCD Unit
