50
*1: This adjustment must be performed not only replacing the MOS unit, but also simply removing the MOS unit.
*2: The pixel that always lights while shaded is called a white wound.
*3: The pixel that does not light while complete exposed is called a black wound. This unit does not have the LCD adjustment of the
camera (LCD flicker adjustment etc.).
*4: If the adjusted data is backed up from the main board before replacement or repair, write the data to the new main board. If parts
other than the main board are not replaced, adjustment is not necessary for items other than "Venus Zoom(PZM)/Backfocus/
GYRO(BF)/Flash(STB)".
IMPORTANT NOTICE (After replacing the Main P.C.B.)
After replacing the Main P.C.B., make sure to perform the
"INITIAL SETTINGS" first, then release the "INITIAL
SETTINGS" in order to proceed the electrical adjustment.
Note:
1. If electrical adjustment or data re-writing is executed
before "INITIAL SETTINGS", suffix code list is never
displayed, and it cannot be chosen suitable suffix code.
2. Never remove the battery during initial setting in process.
To Next Page
