14
Charging the Battery
1
Set the power switch to [OFF].
2
Insert the battery into the camera.
(P13)
3
Open the terminal door.
4
Insert the connection plug of the AC
adaptor into the DC IN socket of the
camera.
THE SOCKET OUTLET SHALL BE
INSTALLED NEAR THE EQUIPMENT AND
SHALL BE EASILY ACCESSIBLE.
5
Plug the AC adaptor into the
electrical outlet.
• The green status indicator
1
blinks and
charging starts.
6
When the
status indicator
stops
blinking, charging is complete.
• After charging is finished, remove the AC
adaptor from the electrical outlet and then
remove the connecting plug from the DC IN
socket.
ª Battery indicator
The remaining battery power is displayed on the LCD monitor. (This is not displayed
when using AC adaptor)
: The battery power is sufficient
: The remaining power is a little low
: The remaining power is low
: Recharge or replace the battery
