Panasonic lumix DMC-LX10 User Manual

97
SQW0740
Focus, Brightness (Exposure) and Colour tone Settings
Taking pictures with Auto Focus
■
When selecting [ ]
You can enlarge the screen to perform more precise settings of the focus position.
• You cannot set the focus position at the edges of the screen.
→ [Rec] / [Motion Picture] → [AF Mode]
Select [ ] and press
Use to set the focus position and press
[MENU/SET]
• The enlarged assist screen will appear for setting the focus
position.
Move [+] to the focus position
Operation Touch operation Description
Touch Moves [+].
— Pinch in / Pinch out Enlarges/reduces the AF area in small steps.
— Enlarges/reduces the AF area in large steps.
—
Switches the enlarged display. (windowed/full
screen)
[DISP.] [Reset] Resets [+] back to the centre.
• The image of a part of the screen can be enlarged or reduced approximately 3 to 6 times. The
image of the entire screen can be enlarged or reduced approximately 3 to 10 times.
• On the assist screen, it is also possible to record a picture by touching [
].

Panasonic lumix DMC-LX10 Specifications

General

Megapixels	20.1 MP
Lens	LEICA DC VARIO-SUMMILUX
Optical Zoom	3x
ISO Range	125-12800 (expandable to 80-25600)
Image Stabilization	5-axis Hybrid O.I.S.
Built-in Flash	Yes
Connectivity	Wi-Fi
Sensor	1.0" MOS Sensor
Shutter Speed	60-1/4000 sec
Display	3.0-inch LCD (1, 040K dots), touchscreen
Video Resolution	4K UHD (3840 x 2160) at 30p/24p
Battery Life	Approx. 260 shots
Weight	310 g (10.9 oz)
Dimensions	105.5 x 60.0 x 42.0 mm
