2. Getting Started
DVQX2068 (ENG)
29
1
Set the camera on/off switch to [OFF].
2
Insert the battery into the camera.
3
Connect the camera USB port and the AC adaptor using
the USB connection cable.
0
Check the direction of the terminals and plug in/out straight holding onto the
plug.
(Inserting these at an angle may cause deformation or malfunction)
4
Connect the AC adaptor to an electrical outlet.
0
The charging light A turns red and charging begins.
Charging Light Indications
Charging light (red)
On: Charging.
Off: Charging has completed.
Blinking: Charging error.
0
Even when the camera on/off switch is set to [OFF] thus turning the camera
off, it consumes power.
When the camera will not be used for a long time, remove the power plug from
the electrical outlet in order to save power.
3
1
2
4
DC-S5E-DVQX2068_eng.book 29 ページ ２０２０年７月２８日 火曜日 午後３時２分
