12. Outdoor Unit Control PCB
CN-TERMINAL pin
(3P, Black)
For communications circuit impedance matching
• A connecting socket (3P, Black) is attached to the terminal plug at the time of shipment from
the factory.
• In the case of link wiring which combines the inter-unit control wiring for multiple systems into
a single communications circuit, When using, refer to the item “4. Auto Address Setting” under
Section “7. TEST RUN”.
LED1, 2 (2P, Red) • LED 1 and 2 blink alternately while auto address setting is in progress.
• Display the alarm contents for alarms which were detected by the outdoor unit.
RUN pin (2P, Black)
Start pin
Short-circuit this pin and apply a pulse signal to start all indoor units in that refrigerant system.
STOP pin (2P, Black) Stop pin
Short-circuit this pin and apply a pulse signal to stop all indoor units in that refrigerant system.
AP pin (2P, Black) Vacuuming pin
• To perform vacuuming of the outdoor unit, short-circuit this pin and then turn the power ON.
All solenoid valves turn ON and vacuuming begins smoothly. (Do not perform auto address
setting at this time.)
• Release the short-circuit to return the unit to normal status.
MODE pin (3P, Black) Indoor unit Heating/Cooling mode change pin
• During the summer season, short-circuit this pin in the cooling mode.
Then, perform auto address setting. When auto address setting is completed, release the
short-circuit to return the unit to normal status.
• When cooling mode is short-circuited, only cooling operation can be used.
• When heating mode is short-circuited, only heating operation can be used.
TEST pin (2P, Black) • This pin is used to test the PCB at the factory.
• When the power is turned ON after this pin has been short-circuited, all output signals will be
output in sequence. (Sequential output does not occur if this pin is short-circuited when the
power is already ON.) Releasing this pin returns the unit to normal control.
CHK pin (2P, Black) When short circuited, test run begins.
(If the remote controller is connected in test run mode, it is automatically cancelled after 1 hour.)
Also, if short-circuit is cancelled, test run mode is cancelled.
DEF pin (2P, Black) When the pin of the main unit is short-circuit in heating mode, defrosting operation is started.
Even if short circuited, defrosting will not be activated immediately.
SILENT plug (2P, White) Can be used when setting the outdoor unit fan in sound absorbing mode.
SA1 (Surge absorber) If “TO INDOOR UNIT” accidently connected to high voltage, use the following method.
1. Replace the wire CN-OC with the wire CN-EMG.
2. Cut off SA1.
Table 2
Table 1
The number of indoor units settings (SW3, SW4)
DO NOT exceed the maximum number of indoor units when making connections.
The indoor unit address setting should also be set less than “16”.
In the event of setting more than “17”, the communication cannot be made between the outdoor and indoor units.
Examples of refrigerant circuit (R.C.) address settings (required when link wiring is used) (SW1, SW2)
System address No.
System address (SW1)
(2P DIP switch)
10 20
System address (SW2)
(Rotary switch)
System 1 (factory setting)
Both OFF
Set to 1 - 9
Set to 0 - 6
21
ON
ON
OFF
Set to 1
System 11
1 ON
21
ON
ON
OFF
Set to 1
System 21
2 ON
21
ON
ON
OFF
Set to 1
System 30
Both ON
21
ON
ON
OFF
Set to 0
2
1
2
1
1
2
2
1
2
1
2
1
1
2
2
1
2
1
2
1
1
2
2
1
Number of indoor units
Indoor unit setting (SW3)
(1P DIP switch)
10
Indoor unit setting (SW4)
(Rotary switch)
10 - 16 unit
(factory setting : 1 unit)
1 - 9 unit
OFF
1
ON
ON
OFF
ON
1
ON
ON
OFF
6
