Seth
Connections
Tt: ee ee ee ee er 5 a ee ee wT. pe ee | Pees ee ee ee eee eee! ns | a
IS LOS YOU NOW tO CUTIICOL WIU) ail det iidi, Iv, eie.
Tuning the TV to your VCR
The VCR supplies a signal to the TV set via the RF
coaxiai cable on channel 36 of the UK broadcasting
system. Your TV must be tuned into this channel in order
to view the VCR playback picture.
If the connection to the TV includes the 21-pin scart cable,
the playback picture can be viewed by selecting AV on
your TV. The RF coaxial cable must still be connected as
shown on page 8, but the TV need not be tuned to
channel 36.
Auto Setup
When the VCR is turned on after connecting the aerial
lead and the mains lead, Auto setup (Auto tuning and Auto
clock setting) starts.
infra-red Remote Conitrolier
ee
Controls and Connection Sockets _
This gives a detailed expianation of the function of each
button, switch and connection socket.
