Chapter 4 Settings — [DISPLAY OPTION] menu
108 - ENGLISH
Adjusting position automatically
1) Press as to select [AUTO SETUP].
2) Press the <ENTER> button.
f The [AUTO SETUP] screen is displayed.
3) Press as to select [POSITION ADJUST].
4) Press qw to switch the item.
[ON] Adjust the screen position and size when automatic setup is executed.
[OFF] Does not perform automatic adjustment.
Adjusting signal level automatically
1) Press as to select [AUTO SETUP].
2) Press the <ENTER> button.
f The [AUTO SETUP] screen is displayed.
3) Press as to select [SIGNAL LEVEL ADJUST].
4) Press qw to switch the item.
[OFF] Does not perform automatic adjustment.
[ON]
Adjusts black level (the [PICTURE] menu → [BRIGHTNESS]) and white level (the [PICTURE] menu
→ [CONTRAST]) when automatic setup is executed.
Note
f [SIGNAL LEVEL ADJUST] may not function properly unless a still image containing clear blacks and whites is input.
[BACKUP INPUT SETTING]
Set the backup function that switches the signal to the backup input signal as seamless as possible when input
signal is disrupted.
Using the SDI input and HDMI input or DVI-D input
1) Press as to select [BACKUP INPUT SETTING].
2) Press the <ENTER> button.
f The [BACKUP INPUT SETTING] screen is displayed.
3) Press as to select [BACKUP INPUT MODE].
4) Press the <ENTER> button.
f The [BACKUP INPUT MODE] screen is displayed.
5) Press as to select the combination of the input and press the <ENTER> button.
Primary input Secondary input Details
[OFF] Disables the backup function.
[DVI-D] [HDMI]
Enables the backup function.[SDI] [DVI-D]
[SDI] [HDMI]
6) Press the <MENU> button.
f The [BACKUP INPUT SETTING] screen is displayed.
7) Press as to select [AUTOMATIC SWITCHING].
f [AUTOMATIC SWITCHING] cannot be selected when [BACKUP INPUT MODE] is set to [OFF].
To Next Page
