Panasonic PT-RZ120

Chapter 7 Appendix — Technical information
192 - ENGLISH
Technical information
PJLink protocol
The network function of this projector supports the PJLink class 1 and class 2, and setting of the projector or
querying of the projector status can be performed from the computer using the PJLink protocol.
Control commands
The following table lists the PJLink protocol commands that can be used to control the projector.
f x characters in tables are non-specic characters.
Class Command Control details
Parameter/response
string
Remark
1 POWR Power supply control
0 Standby
1 Power on
1 POWR ?
Power supply status
query
0 Standby
1 Power on
2 Preparing for switching off the projector
1, 2
INPT Input selection
11 RGB1
12 RGB2
INPT ? Input selection query 31 DVI-D
32 HDMI
33 DIGITAL LINK
34 SDI
1
AVMT Shutter control 30 Shutter function disabled (shutter: open)
AVMT ? Shutter status query 31 Shutter function enabled (shutter: closed)
1 ERST ? Error status query xxxxxx
1st byte
Indicates fan errors, and
returns 0 - 2.
f 0 = No error is
detected
f 1 = Warning
f 2 = Error
2nd byte
Indicates light source errors,
and returns 0 or 2.
3rd byte
Indicates temperature errors,
and returns 0 - 2.
4th byte Returns 0.
5th byte Returns 0.
6th byte
Indicates other errors, and
returns 0 - 2.
1 LAMP ?
Light source status
query
AAAA X BBBB Y
AAAA: Light source 1 runtime
X: 0 = Light source 1 off, 1 = Light source 1 on
BBBB: Light source 2 runtime
Y: 0 = Light source 2 off, 1 = Light source 2 on
1, 2 INST ?
Input selection list
query
11 12 31 32 33 34 ―
1 NAME ? Projector name query xxxxx
Returns the name set in [PROJECTOR NAME] of [NETWORK
SETUP].
1 INF1 ?
Manufacturer name
query
Panasonic Returns manufacturer name.
1 INF2 ? Model name query PT-RZ120 Returns model name.
1 INF0 ?
Other information
queries
xxxxx Returns information such as version number.
1 CLSS ?
Class information
query
2 Returns class for PJLink.
2 SNUM ? Serial number query xxxxxxxxx Returns serial number.
2 SVER ? Software version query xxxxxxxxx Returns version number.
2 INNM ?
Input terminal name
query
11 / RGB1
Returns input terminal name.
12 / RGB2
31 / DVI-D
32 / HDMI
33 / DIGITAL LINK
34 / SDI
2 IRES ?
Input signal resolution
query
AAAAxBBBB
AAAA: Horizontal resolution
BBBB: Vertical resolution
