Panasonic PT-RZ120

Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 129
Interrelation of luminance and runtime
The projector can be operated at arbitrary brightness and duration of use by combining the settings of [MAX
LIGHT OUTPUT LEVEL], [LIGHT OUTPUT], and [CONSTANT MODE] in [BRIGHTNESS CONTROL SETUP].
Interrelation of luminance and runtime is as follows. Make the settings depending on your desired duration of use
and brightness of the projected image.
Values of the luminance and runtime are rough estimations.
f To set the projector based on the duration of use
Duration of use
(hour)
When [CONSTANT MODE] is set to [OFF] When [CONSTANT MODE] is set to [AUTO] or [PC]
[MAX LIGHT
OUTPUT LEVEL]
(%)
[LIGHT OUTPUT]
(%)
Luminance (lm)
[MAX LIGHT
OUTPUT LEVEL]
(%)
[LIGHT OUTPUT]
(%)
Luminance (lm)
20 000 100.0 100.0 12 000 100.0 64.6 7 700
24 000 100.0 100.0 12 000 100.0 60.5 7 200
27 000 100.0 100.0 12 000 100.0 57.7 6 900
31 000 100.0 78.2 9 300 100.0 54.3 6 500
35 000 100.0 58.5 7 000 100.0 51.1 6 100
40 000 ― ― ― 100.0 47.5 5 700
f To set the projector based on luminance
Luminance (lm)
When [CONSTANT MODE] is set to [OFF] When [CONSTANT MODE] is set to [AUTO] or [PC]
[MAX LIGHT
OUTPUT LEVEL]
(%)
[LIGHT OUTPUT]
(%)
Runtime (hour)
[MAX LIGHT
OUTPUT LEVEL]
(%)
[LIGHT OUTPUT]
(%)
Runtime (hour)
12 000 100.0 100.0 27 000 ― ― ―
11 000 100.0 91.7 28 500 100.0 91.7 1 000
10 000 100.0 83.3 30 000 100.0 83.3 4 300
9 000 100.0 75.0 31 500 100.0 75.0 11 000
8 000 100.0 66.7 33 000 100.0 66.7 18 000
7 000 100.0 58.3 35 000 100.0 58.3 26 000
6 000 100.0 50.0 37 000 100.0 50.0 36 000
5 000 ― ― ― 100.0 41.7 49 000
4 000 ― ― ― 100.0 33.3 66 000
Note
f The runtime may be shorter than the estimation due to the inuence of characteristics of each light source, conditions of use, installation
environment, etc.
f The duration of use is referred to as the runtime when you use the projector successively. The duration of use is an estimated duration and
is not the warranty period.
f If the runtime exceeds 20 000 hours, replacement of the components inside the projector may be required. Consult your dealer for details.
[LIGHT OUTPUT]
Adjust the brightness of light source.
The setting is reected when it is already set with “Initial setting (operation setting)” (x page 60) in the [INITIAL
SETTING] screen or with the [PROJECTOR SETUP] menu → [OPERATION SETTING]. The [LIGHT OUTPUT]
setting is synchronized with the [PROJECTOR SETUP] menu → [OPERATION SETTING] → [LIGHT OUTPUT].
The most recent setting is reected in both items.
1) Press as to select [LIGHT OUTPUT].
2) Press qw to adjust.
Operation
Adjustment
Range of adjustment
Brightness Runtime (estimate)
Press w.
The screen becomes brighter. The runtime becomes shorter.
8.0 % - 100.0 %
Press q.
The screen becomes darker. The runtime becomes longer.
Note
f [LIGHT OUTPUT] can be adjusted individually for each setting item of [OPERATING MODE].
f In such a case when conguring multiple screens with multiple projectors, uniformity of brightness between multiple screens can be
obtained by adjusting [LIGHT OUTPUT].
