Signal name
(SIGNAL FORMAT)
Resolution
(Dots)
Scanning freq.
Dot clock freq.
(MHz)
Compatible signal
Horizontal
(kHz)
Vertical
(Hz)
RGB DVI-D HDMI DL
1920 x 1200/50 1 920 x 1 200 61.8 49.9 158.3
l l l l
1920 x 1200/60 1 920 x 1 200
*5
74.6 59.9 193.3
l
― ― ―
1920 x 1200/60RB 1 920 x 1 200
*4
74.0 60.0 154.0
l l l l
*1 Pixel-Repetition signal (dot clock frequency 27.0 MHz) only
*2 The signal with 1/1.001x vertical scanning frequency is also supported.
*3 YP
B
P
R
4:2:0 format only
*4 VESA CVT-RB (Reduced Blanking)-compliant
*5 Samples the pixels in the image processing circuit and projects the image.
Note
f A signal with a different resolution is converted to the number of display dots. The number of display dots is 1 920 x 1 200.
f The “i” at the end of the resolution indicates an interlaced signal.
f When interlaced signals are connected, ickering may occur on the projected image.
f When the DIGITAL LINK connection is made with the long-reach communication method, the signal that the projector can receive is up to
1080/60p (1 920 x 1 080 dots, dot clock frequency 148.5 MHz).
f Even if it is the signal listed in the list of compatible signals, it may not be displayed by the projector if the video signal is recorded in a
special format.
List of plug and play compatible signals
The following table species the video signals compatible with plug and play.
Signal with l in the plug and play compatible signal column is the signal described in the EDID (extended display
identication data) of the projector. For the signal without l in the plug and play compatible signal column, the
resolution may not be selected on the computer even if the projector is supporting it.
f Input corresponding to each item in the plug and play signal column is as follows.
g RGB2: RGB2 input
g DVI-D: DVI-D input
g HDMI: HDMI input
g DIGITAL LINK: DIGITAL LINK input
Signal name
(SIGNAL FORMAT)
Resolution
(Dots)
Scanning
freq.
Dot
clock
freq.
(MHz)
Plug and play compatible signal
Horizontal
(kHz)
Vertical
(Hz)
RGB2
DVI-D HDMI DIGITAL LINK
EDID1 EDID2 EDID3 4K/60p 4K/30p 2K 4K/60p 4K/30p 2K
480/60i 720 x 480i 15.7 59.9 13.5 ― ― ― ― ― ― ― ― ― ―
576/50i 720 x 576i 15.6 50.0 13.5 ― ― ― ― ― ― ― ― ― ―
480/60i
720
(1 440) x 480i
*1
15.7 59.9 27.0 ― ― ― ― ― ― ― ― ― ―
576/50i
720
(1 440) x 576i
*1
15.6 50.0 27.0 ― ― ― ― ― ― ― ― ― ―
480/60p 720 x 480 31.5 59.9 27.0 ―
l
―
l l l l l l l
576/50p 720 x 576 31.3 50.0 27.0 ―
l
―
l l l l l l l
720/60p 1 280 x 720 45.0 60.0
*2
74.3 ―
l
―
l l l l l l l
720/50p 1 280 x 720 37.5 50.0 74.3 ―
l
―
l l l l l l l
1080/60i 1 920 x 1 080i 33.8 60.0
*2
74.3 ―
l
―
l l l l l l l
1080/50i 1 920 x 1 080i 28.1 50.0 74.3 ―
l
―
l l l l l l l
1080/24p 1 920 x 1 080 27.0 24.0
*2
74.3 ―
l
―
l l l l l l l
1080/24sF 1 920 x 1 080i 27.0 48.0
*2
74.3 ― ― ― ― ― ― ― ― ― ―
1080/25p 1 920 x 1 080 28.1 25.0 74.3 ―
l
―
l l l l l l l
1080/30p 1 920 x 1 080 33.8 30.0
*2
74.3 ―
l
―
l l l l l l l
1080/60p 1 920 x 1 080 67.5 60.0
*2
148.5 ―
l
―
l l l l l l l
1080/50p 1 920 x 1 080 56.3 50.0 148.5 ―
l
―
l l l l l l l
3840 x 2160/24p 3 840 x 2 160 54.0 24.0
*2
297.0 ― ― ― ―
l l
―
l l
―
3840 x 2160/25p 3 840 x 2 160 56.3 25.0 297.0 ― ― ― ―
l l
―
l l
―
3840 x 2160/30p 3 840 x 2 160 67.5 30.0
*2
297.0 ― ― ― ―
l l
―
l l
―
3840 x 2160/60p
3 840 x 2 160 135.0 60.0
*2
297.0 ― ― ― ―
l
*3
― ―
l
*3
― ―
3 840 x 2 160 135.0 60.0
*2
594.0 ― ― ― ―
l
― ― ― ― ―
3840 x 2160/50p
3 840 x 2 160 112.5 50.0 297.0 ― ― ― ―
l
*3
― ―
l
*3
― ―
3 840 x 2 160 112.5 50.0 594.0 ― ― ― ―
l
― ― ― ― ―
