Panasonic PT-RZ120

Chapter 7 Appendix — Technical information
210 - ENGLISH
Signal name
(SIGNAL FORMAT)
Resolution
(Dots)
Scanning
freq.
Dot
clock
freq.
(MHz)
Plug and play compatible signal
Horizontal
(kHz)
Vertical
(Hz)
RGB2
DVI-D HDMI DIGITAL LINK
EDID1 EDID2 EDID3 4K/60p 4K/30p 2K 4K/60p 4K/30p 2K
1366 x 768/50 1 366 x 768 39.6 49.9 69.0 ― ― ― ― ― ― ― ― ― ―
1366 x 768/60 1 366 x 768 47.7 59.8 85.5 ― ― ― ― ― ― ― ― ― ―
1400 x 1050/50 1 400 x 1 050 54.1 50.0 99.9 ― ― ― ― ― ― ― ― ― ―
1400 x 1050/60
1 400 x 1 050 64.0 60.0 108.0 ― ― ― ― ― ― ― ― ― ―
1 400 x 1 050 65.3 60.0 121.8 ― ― ― ― ― ― ― ― ― ―
1 400 x 1 050 65.2 60.0 122.6
l
―
l l l l l l l l
1400 x 1050/72 1 400 x 1 050 78.8 72.0 149.3 ― ― ― ― ― ― ― ― ― ―
1400 x 1050/75 1 400 x 1 050 82.2 75.0 155.9 ― ― ― ― ― ― ― ― ― ―
1440 x 900/50 1 440 x 900 46.3 49.9 86.8 ― ― ― ― ― ― ― ― ― ―
1440 x 900/60 1 440 x 900 55.9 59.9 106.5 ― ― ― ― ― ― ― ― ― ―
1600 x 900/50 1 600 x 900 46.4 49.9 96.5 ― ― ― ― ― ― ― ― ― ―
1600 x 900/60 1 600 x 900 55.9 60.0 119.0
l
―
l l l l l l l l
1600 x 1200/50 1 600 x 1 200 61.8 49.9 131.5 ― ― ― ― ― ― ― ― ― ―
1600 x 1200/60 1 600 x 1 200 75.0 60.0 162.0
l
―
l l l l l l l l
1680 x 1050/50 1 680 x 1 050 54.1 50.0 119.5 ― ― ― ― ― ― ― ― ― ―
1680 x 1050/60 1 680 x 1 050 65.3 60.0 146.3 ― ― ― ― ― ― ― ― ― ―
1920 x 1080/50 1 920 x 1 080 55.6 49.9 141.5 ― ― ― ― ― ― ― ― ― ―
1920 x 1080/60
1 920 x 1 080
*4
66.6 59.9 138.5 ― ― ― ― ― ― ― ― ― ―
1 920 x 1 080
*5
67.2 60.0 173.0 ― ― ― ― ― ― ― ― ― ―
1920 x 1200/50 1 920 x 1 200 61.8 49.9 158.3 ― ― ― ― ― ― ― ― ― ―
1920 x 1200/60 1 920 x 1 200
*5
74.6 59.9 193.3 ― ― ― ― ― ― ― ― ― ―
1920 x 1200/60RB 1 920 x 1 200
*4
74.0 60.0 154.0
l
―
l l l l l l l l
*1 Pixel-Repetition signal (dot clock frequency 27.0 MHz) only
*2 The signal with 1/1.001x vertical scanning frequency is also supported.
*3 YP
B
P
R
4:2:0 format only
*4 VESA CVT-RB (Reduced Blanking)-compliant
*5 Samples the pixels in the image processing circuit and projects the image.
Note
f A signal with a different resolution is converted to the number of display dots. The number of display dots is 1 920 x 1 200.
f The “i” at the end of the resolution indicates an interlaced signal.
f When interlaced signals are connected, ickering may occur on the projected image.
f When the DIGITAL LINK connection is made with the long-reach communication method, the signal that the projector can receive is up to
1080/60p (1 920 x 1 080 dots, dot clock frequency 148.5 MHz).
f Even if it is the signal listed in the list of compatible signals, it may not be displayed by the projector if the video signal is recorded in a
special format.
