5) Press as to select one item to adjust.
6) Press the <ENTER> button.
f The individual adjustment screen of the selected item is displayed.
f If you select [LENS THROW RATIO] or [BALANCE] in Step 5), you can also press qw to display the
individual adjustment screen.
7) Press qw to adjust.
f Press asqw to adjust when [KEYSTONE] is selected in Step 5).
[LENS THROW RATIO]
Set the throw ratio. The adjustable range is 0.9 ~2.3.
Select a value close to the value obtained by dividing the actual projection distance by the
projection screen width.
[KEYSTONE]
[H]
[V]
[BALANCE]
Note
f Pressing the <ENTER> button while the individual adjustment screen is displayed can switch to the individual adjustment screen of other
items.
Setting
[CORNER CORRECTION]
1) Press as to select [SCREEN ADJUSTMENT].
2) Press the <ENTER> button.
f The [SCREEN ADJUSTMENT] screen is displayed.
3) Press as to select [CORNER CORRECTION].
4) Press the <ENTER> button.
f The [CORNER CORRECTION] screen is displayed.
5) Press as to select the item to adjust.
6) Press the <ENTER> button.
f The individual adjustment screen of the selected item is displayed.
7) Press asqw to adjust.
ENGLISH - 63
Chapter 4 Settings - [POSITION] menu
