Pin No. Mark I/O Function
25 N.C. - No Connection
26 FL_CS1 O FL Driver Chip Select (
Master )
27 N.C. - No Connection
28 FL_CLK O Serial Clock to FL Driver
29 N.C. O Reset Input(ACTIVE L)
30 FL_DOUT O Serial Data To FL Driver
/ ( Output )
31 RXD - No Connection (For
Download Software)
32 TXD - No Connection (For
Download Software)
33 SCLK - No Connection (For
Download Software)
34 BUSY - No Connection (For
Download Software)
35 N.C. - No Connection
36 N.C. - No Connection
37 N.C. - No Connection
38 N.C. - No Connection
39 MCLK O CD Command CLK
Output
40 MUTE_A O Audio Mute
41 EPM - -
42 MDATA_ /
OUT
O CD Command Data
Output
43 MLD O CD Command Load
Output/
44 N.C. - RDS Clock Input
45 N.C. - No Connection
46 CE - -
47 DCDET I DC Detect Input
48 STATUS I CD Servo LSI Status
Input(Inverted)
49 PCONT O Main Transformer
Control Output
50 PLAY_SW I Play Sw (CR16)
51 STOCK_SW I Stock Sw (CR16)
52 OP_SW I Open Sw (CR16)
53 POS I Position Sw (CR16)
54 BT_SW I Bottom Sw (CR16)
55 M1_R O Changer Motor 1
Reverse Control
56 M1_F O Changer Motor 1
Forward Control
