8.1.6. TPS Inspection
Purpose : To check the TPS.
Below is the procedures for this mode.
Step 1: Enter into Doctor mode (For more information refer to section 8.1 on key operation to enter into
this mode).
Step 2 : Press [ ] button on remote control. Enter into TPS Test mode. (During
this mode)
- Software will start checking for existence of cassette in Deck.
- If the Deck does not contain any cassette, it shall end the test and
displays the result of the test.
- The test will start by playing the Deck in forward direction for 1 sec and
then FF TPS.
- If TPS signal is OK, the Deck shall be ejected. Below is information on
the TPS under 3 examples.
1. If ERROR Flag is set "ERROR" shall be displayed. TPS check result
shall not be shown in this case.
2. If Deck TPS check = OK
3. If Deck TPS check = NG
24
