Panasonic SA-PMX82EB - Mechanical Replacement Parts List

73
15.4. Mechanical Replacement Parts List
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
CABINET AND
CHASSIS
1 TZH3QEZ003 10P FFC WIRE
(MECHA-MAIN)
1
2 TZH3QEZ011 10P FFC (DAB-
MAIN)
1
3 TZH3QKZ012 19P FFC (PANEL-
MAIN)
1
4 REX1823 7P WIRE (USB-
MAIN)
1
6 TNMX030 5P WIRE (PANEL-
MAIN)
1
7 REX1827-1 9P WIRE (BLUE-
TOOTH-MAIN)
1
8 REX1526 15P WIRE (SMPS-
MAIN)
1
9 REX1541 2P WIRE (SMPS-
PANEL)
1
12 RGR0474J-A REAR CABINET 1 82EGK,
82EGS,
82EBK
12 RGR0474J-B REAR CABINET 1 82GNS
12 RGR0474J-C REAR CABINET 1 82MEBK
12 RGR0474J-D REAR CABINET 1 84EGK,
84EGS
16 RKM0766-K TOP CABINET 1 82EGK,
82EBK,
82MEBK,
84EGK
16 RKM0766-S TOP CABINET 1 82EGS,
82GNS,
84EGS
17 RYP2063J-K FRONT PANEL
ASS’Y
1 82EGK,
82EBK
17 RYP2063J-S FRONT PANEL
ASS’Y
1 82EGS,
82GNS
17 RYP2063L-K FRONT PANEL
ASS’Y
1 82MEBK
17 RYP2063K-K FRONT PANEL
ASS’Y
1 84EGK
17 RYP2063K-S FRONT PANEL
ASS’Y
1 84EGS
17-1 RGK2605-K VOLUME RING
ORNAMENT
1 82EGK,
82EBK,
82MEBK,
84EGK
17-1 RGK2605-S VOLUME RING
ORNAMENT
1 82EGS,
82GNS,
84EGS
17-2 RGW0458-K TUNE KNOB 2 82EGK,
82EBK,
82MEBK,
84EGK
17-2 RGW0458-S TUNE KNOB 2 82EGS,
82GNS,
84EGS
17-3 RGW0431-S VOLUME KNOB
ASS’Y
1 82EGS,
82GNS,
84EGS
17-3 RGW0431-K VOLUME KNOB
ASS’Y
1 82EGK,
82EBK,
82MEBK,
84EGK
22 TEKX073 PC SHEET 1
