76
IC5802 C0DAAYY00072 IC 1
CAPACITORS
C2902 F1H1H103B047 0.01uF 50V 1
C2903 F1H1H682B047 6800pF 50V 1
C2905 F2A1H101A147 100uF 50V 1
C2906 F2A1V560B146 56uF 35V 1
C5700 F1BAF102A216 1000pF AC250
<= Vac <315
1
C5701 F0CAF104A218 0.1uF AC250
<= Vac <315
1
C5702 F0CAF104A218 0.1uF AC250
<= Vac <315
1
C5704 F1BAF4710005 470pF AC250
<= Vac <315
1
C5705 F1BAF4710005 470pF AC250
<= Vac <315
1
C5706 F1BAF102A216 1000pF AC250
<= Vac <315
1
C5708 F1B3D102A132 1000pF 2000V 1
C5720 F2A2G820A354 82uF 400V 1
C5721 F0C2K103A053 0.01uF 800V 1
C5722 F1H1H101B052 100pF 50V 1
C5723 F2A1H100B411 10uF 50V 1
C5724 F1B3D101A132 100pF 2000V 1
C5725 F1H1H681B047 680pF 50V 1
C5727 F1H1H100B051 10pF 50V 1
C5728 F1H1H102B047 1000pF 50V 1
C5729 F2A1H100B411 10uF 50V 1
C5730 F1H1H104B047 0.1uF 50V 1
C5800 F1H1H101B052 100pF 50V 1
C5801 F1J1H105A918 1uF 50V 1
C5802 F2A1V4710074 470uF 35V 1
C5803 F2A1V4710074 470uF 35V 1
C5805 F1H1H104B047 0.1uF 50V 1
C5807 F1H1H102B047 1000pF 50V 1
C5808 F2A0J101A208 100uF 6.3V 1
C5810 F1H1H104B047 0.1uF 50V 1
C5811 F2A1E3320065 3300uF 25V 1
C5812 F1H1H102B047 1000pF 50V 1
C5829 F1H1H104B047 0.1uF 50V 1
C5841 F1H1H102B047 1000pF 50V 1
C5842 F1H1H104B047 0.1uF 50V 1
C5843 F1H1H104B047 0.1uF 50V 1
C5844 F1H1H104B047 0.1uF 50V 1
C5845 F1H1H102B052 1000pF 50V 1
DIODES
D2900 B0JCPD000025 DIODE 1
D5701 B0EDNR000001 DIODE 1
D5702 B0EAKT000063 DIODE 1
D5703 DZ2J200M0L DIODE 1
D5704 DZ2J200M0L DIODE 1
D5705 B0EAMM000057 DIODE 1
D5707 DA2J10100L DIODE 1
D5708 B0JCPD000039 DIODE 1
D5709 B0EAKT000063 DIODE 1
D5710 DZ2J075M0L DIODE 1
D5711 DA2J10100L DIODE 1
D5712 DA2J10100L DIODE 1
D5801 B0ADRL000001 DIODE 1
D5802 B0HBSM000054 DIODE 1
D5803 DA2J10100L DIODE 1
D5804 DA2J10100L DIODE 1
D5841 DZ2J075M0L DIODE 1
DZ5701 D4EAY5110006 DIODE 1
INDUCTORS
L2900 G0A330ZA0045 INDUCTOR 1
LB2901 J0JKB0000020 INDUCTOR 1
L5701 G0B103G00023 INDUCTOR 1
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
L5702 G0B103G00023 INDUCTOR 1
L5801 G0A330ZA0045 INDUCTOR 1
TRANSISTORS
Q5701 B1CERT000009 TRANSISTOR 1
Q5702 B1BABG000007 TRANSISTOR 1
Q5801 B1ABGC000001 TRANSISTOR 1
Q5802 B1ABGC000001 TRANSISTOR 1
Q5803 B1ADCF000001 TRANSISTOR 1
Q5804 B1ADMF000001 TRANSISTOR 1
Q5806 B1ABGC000001 TRANSISTOR 1
Q5807 B1ABGC000001 TRANSISTOR 1
QR5806 B1GBCFGG0030 TRANSISTOR 1
TRANSFORMER
T5700 G4DYZ0000085 SWITCHING TRANS-
FORMER
1
PHOTO COUPLER
PC5721 B3PBA0000579 PHOTO COUPLER 1
PC5723 B3PBA0000579 PHOTO COUPLER 1
PC5724 B3PBA0000579 PHOTO COUPLER 1
JACKS
P5701 K2AA2B000011 AC INLET 1
CABLE HOLDER
H2015 K1ZZ00000836 15P CABLE HOLDER 1
RESISTORS
R2900 D0GB103JA065 10K 1/10W 1
R2901 D1BB1003A074 100K 1/10W 1
R2902 D1BB1002A074 10K 1/10W 1
R2903 D1BB1002A074 10K 1/10W 1
R5700 ERJ12YJ125U 1.2M 1/2W 1
R5701 ERJ12YJ125U 1.2M 1/2W 1
R5702 ERJ1TYJ104U 100K 1W 1
R5703 ERJ1TYJ104U 100K 1W 1
R5704 D0GF224JA048 220K 1/4W 1
R5705 D0GF224JA048 220K 1/4W 1
R5719 D0GB823JA065 82K 1/10W 1
R5720 D0GD220JA052 22 1/8W 1
R5721 D0GD222JA052 2.2K 1/8W 1
R5723 ERJ14YJ220U 22 1/2W 1
R5724 ERJ14YJ220U 22 1/2W 1
R5725 ERX2LJ82MP 0.08 2W 1
R5726 D0GB472JA065 4.7K 1/10W 1
R5727 D0GB472JA065 4.7K 1/10W 1
R5728 D0GD103JA052 10K 1/8W 1
R5729 D0GD331JA052 330 1/8W 1
R5730 D0GB562JA065 5.6K 1/10W 1
R5731 D0GB104JA065 100K 1/10W 1
R5732 D0GB103JA065 10K 1/10W 1
R5801 D1BB6801A074 6.8K 1/10W 1
R5802 D0GB224JA065 220K 1/10W 1
R5803 D1BB8201A074 8.2K 1/10W 1
R5804 D1BB1802A074 18K 1/10W 1
R5805 D1BB1002A074 10K 1/10W 1
R5806 D0GB103JA065 10K 1/10W 1
R5807 D1BB7502A074 75K 1/10W 1
R5808 D0GB472JA065 4.7K 1/10W 1
R5809 D0GD681JA052 680 1/8W 1
R5810 D0GB221JA065 220 1/10W 1
R5812 D1BB2401A074 2.4K 1/10W 1
R5813 D0GB100JA065 10 1/10W 1
R5814 ERJ6GEYJ220V 22 1/8W 1
R5815 D0GB104JA065 100K 1/10W 1
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
To Next Page
