R9305 D0GD3R3JA052 3.3 1/8W 1
R9306 D0GF390JA048 39 1/4W 1
R9307 D0GF390JA048 39 1/4W 1
R9308 D0GB101JA065 100 1/10W 1
R9309 D0GB101JA065 100 1/10W 1
R9310 D0GB101JA065 100 1/10W 1
R9312 D0GB100JA065 10 1/10W 1
PRINTED CIRCUIT
BOARDS
PCB6 TNPA6419 IR SENSOR P.C.B 1 (RTL)
CAPACITORS
C920 F1H1A105A113 1uF 10V 1
REMOTE SENSOR
IR921 B3RAD0000225 REMOTE SENSOR 1
CONNECTORS
ZJ920 K1KY04B00023 4P CONNECTOR 1
RESISTORS
R920 D0GB470JA065 47 1/10W 1
R921 D0GB101JA065 100 1/10W 1
PRINTED CIRCUIT
BOARDS
1
PCB7 TNPA6473AD HEADPHONE P.C.B 1 (RTL)
82EBK,
82GNS
PCB7 TNPA6473AM HEADPHONE P.C.B 1 (RTL)
82MEBK
PCB7 TNPA6473AE HEADPHONE P.C.B 1 (RTL)
82EGK,
82EGS
PCB7 TNPA6473AF HEADPHONE P.C.B 1 (RTL)
84EGK,
84EGS
CAPACITORS
C3000 F1H1C104A178 0.1uF 16V 1
C3001 F1H1C104A178 0.1uF 16V 1
C3003 F1H1C104A178 0.1uF 16V 1
C3004 F1H1C104A178 0.1uF 16V 1
INDUCTORS
LB3000 J0JGC0000070 INDUCTOR 1
LB3001 J0JGC0000070 INDUCTOR 1
LB3002 D0GBR00J0004 0 1/10W 1
CONNECTORS
P3000 K1KY06AA1356 6P CONNECTOR 1
JACKS
JK3000 K2HC1YYB0033 JK HEADPHONE 1
RESISTORS
R3000 D0GB471JA065 470 1/10W 1
R3001 D0GB471JA065 470 1/10W 1
PRINTED CIRCUIT
BOARDS
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
PCB8 REP4945B CD INTERFACE
P.C.B
1
SWITCHES
S7201 K0L1BA000158 SW 1
CONNECTOR
CN7001 K1MY05BA0565 5P CONNECTOR 1
CN7002 K1MN10B00016 10P CONNECTOR 1
PRINTED CIRCUIT
BOARDS
PCB9 REP5310A DAB P.C.B 1 (RTL)
INTEGRATED CIR-
CUITS
IC1 RFKWFCRS32EB IC 1
IC2 C1CB00004533 IC 1
CAPACITORS
C2 F1G1H560A834 56pF 50V 1
C3 F1G1H330A834 33pF 50V 1
C4 F1G1H560A834 56pF 50V 1
C8 F1G1A1040006 0.1uF 10V 1
C9 F1G1A1040006 0.1uF 10V 1
C10 F1G1A1040006 0.1uF 10V 1
C11 F1H0J4750004 4.7uF 6.3V 1
C12 F1G1A1040006 0.1uF 10V 1
C13 F1H0J4750004 4.7uF 6.3V 1
C14 F1G1A1040006 0.1uF 10V 1
C16 F1G1A1040006 0.1uF 10V 1
C17 F1H0J4750004 4.7uF 6.3V 1
C18 F1G1A1040006 0.1uF 10V 1
C19 F1G1A1040006 0.1uF 10V 1
C20 F1G1A1040006 0.1uF 10V 1
C21 F1G1A1040006 0.1uF 10V 1
C22 F1G1A1050004 1uF 10V 1
C23 F1G1H223A739 0.022uF 50V 1
C24 F1H1H223B047 0.022uF 50V 1
C25 F1G1A1050004 1uF 10V 1
C27 F1G1A1050004 1uF 10V 1
C29 F1G1C103A146 0.01uF 16V 1
C32 F1G1A1040006 0.1uF 10V 1
C33 F1G1A1040006 0.1uF 10V 1
C37 F1G1C103A146 0.01uF 16V 1
C38 F1G1A1040006 0.1uF 10V 1
C41 F1G1H471A541 470pF 50V 1
C42 F1G1H471A541 470pF 50V 1
C43 F1G1A1050004 1uF 10V 1
C47 F1G1A1050004 1uF 10V 1
C48 F1G1H102A830 1000pF 50V 1
C49 F1G1H223A739 0.022uF 50V 1
C50 F1G1H3R3A784 3.3pF 50V 1
COIL AND INDUC-
TORS
L2 J0JYC0000051 INDUCTOR 1
L3 G1C68NJA0037 INDUCTOR 1
L4 G1CR12GA0007 INDUCTOR 1
L5 G1CR22GA0007 INDUCTOR 1
LB7 J0JYC0000051 INDUCTOR 1
LB8 J0JYC0000051 INDUCTOR 1
OSCILLATORS
X1 H0J384500002 OSCILLATORS 1
JACKS
