Panasonic SA-XR57 - Home Theater Connections: Picture Quality; Connecting for High-Quality Pictures; Video Terminal Information

6
RQT8552
Connection cable (All cables are sold separately)
• Check terminals on your TV, DVD recorder or DVD player and obtain corresponding connection cables.
• Select one and use it for connection when your TV, DVD recorder or DVD player has two or more video terminals. The component
video terminal can produce more accurate colours than the S video terminal.
See page 13 for connecting the unit to a cable box or satellite receiver.
Connecting the unit to a TV, DVD recorder and DVD player
To enjoy high-quality pictures
Video cable
S-VIDEO connection cable Video connection cable
Audio cable
Optical fiber cable Coaxial cable
Insert the cable after
making sure shapes
match.
How to connect the optical fiber
cable
• Do not sharply bend the optical
fiber cable.
(TV/STB)
OPTICAL1
YPB PR Y YPB PR PB PR
BI-WIRE
LF
HF
DIGITAL IN
(DVD RECORDER) (DVD PLAYER) (CD)
OPTICAL2 COAXIAL1 COAXIAL2
OUT (DVD RECORDER) IN
S VIDEO
OUT
TV MONITOR
IN
DVD PLAYER
IN
DVD RECORDER
IN
TV/STB
OUT
VIDEO
TV MONITOR DVD PLAYER
IN IN
DVD RECORDER
IN
VCR
IN
TV/STB
L
R
IN
CD
CENTER
SUBWOOFER SURROUND FRONT
DVD/DVD 6CH IN
AUDIO
IN
DVD RECORDER
IN
VCR
IN
TV/STB
OUT
SUBWOOFER
LR
FRONT AFRONT B
LR
CENTER SURROUND
LR
SURROUND BACK
LR
TV MONITOR OUT DVD RECORDER IN
COMPONENT VIDEO
TV / STB IN
SPEAKERS
LOOP EXTLOOP EXTLOOP EXT
AM ANTFM ANT
LOOP ANT
GND
Y
P
B
P
R
Y
P
B
P
R
TV
The unit’s rear view
DVD player
DVD recorder
COMPONENT
VIDEO IN
S-VIDEO
IN
DIGITAL
AUDIO OUT
(COAXIAL)
S-VIDEO
OUT
DIGITAL
AUDIO OUT
(OPTICAL)
S-VIDEO
OUT
COMPONENT
VIDEO OUT
Changing the digital input
settings
For example, you can connect
the unit to a DVD player that
makes optical output only by
performing the steps instructed
in “Changing the digital input
settings” (á page 32).
• Make additional connections instructed on page
9 for enjoying TV sounds on multi channels.
Points regarding video terminals
• The input video signal can be sent out through an output terminal of the same type only.
• The component video terminals (colour-difference video terminal) outputs red (P
R), blue (PB), and luminance (Y)
signals separately. The terminals reproduces colours with greater accuracy for this reason.
Note
Home Theater connections
Home Theater connections
ENGLISH
