12
RQT9772
Attach the stands if necessary. If not, proceed to step 3.
Place the main unit in the desired position and attach each cord onto
the rack or table.
≥ Make sure that the slack of the cord is minimal.
[A]: With basic stands [B]: With 30
o
stands [C]: With 80
o
stands
A Screw (supplied)
≥ Tighten securely.
B Screw eye
≥Attach at a position capable of supporting over 33 kg.
≥Depending on the placement of the main unit, the screwing position of
the screw eye may differ.
SC-HTB170EGEBGN_RQT9772-B.book 12 ページ ２０１３年２月４日 月曜日 午前９時５分
To Next Page
