Panasonic SC-HTB170 User Manual

30
RQT9772
Specifications

≥ Specifications are subject to change without notice.
≥ Weight and dimensions are approximate.
≥
Total harmonic distortion is measured by a digital spectrum analyzer.
AMPLIFIER SECTION
RMS output power: Dolby Digital Mode
Front ch
30 W per channel (6 ≠), 1 kHz, 10 % THD
Subwoofer ch
60 W per channel (3 ≠), 100 Hz, 10 % THD
Total RMS Dolby Digital mode power
120 W
TERMINAL SECTION
HDAVI Control
This unit supports “HDAVI Control 5” function.
HDMI AV input
(BD/DVD) 1
Input connector Type A (19 pin)
HDMI AV output
(TV (ARC)) 1
Output connector Type A (19 pin)
Digital audio input
Optical digital input Optical terminal
Sampling frequency
32 kHz, 44.1 kHz, 48 kHz
88.2 kHz, 96 kHz (only LPCM)
Audio Format
LPCM, Dolby Digital, DTS Digital Surround
IR Blaster
Term inal Type 3.5 mm jack
USB Port For service use only.
SPEAKER SECTION
Front speakers (Built-in)
Type
2 way, 2 speaker system (Bass Reflex)
Woofer
5.7 cm Cone type
Tweeter
2.5 cm Semi-dome type
Subwoofer (Built-in)
Type
1 way, 2 speaker system (Bass Reflex)
Woofer
8cmConetypek2
GENERAL
Power consumption
22 W
Power consumption in standby mode
(When the other connected devices are turned off)
Approx. 0.4 W
Power supply AC 220 V to 240 V, 50 Hz
Dimensions (WkHkD)
950 mmk66 mmk105 mm
Mass Approx. 3.4 kg
For wall mounting
Dimensions (WkHkD)
950 mmk105 mmk66 mm
Mass Approx. 3.4 kg
With basic stands
Dimensions (WkHkD)
950 mmk79 mmk105 mm
Mass 3.45 kg
With 30
o
stands
Dimensions (WkHkD)
950 mmk99 mmk113 mm
Mass 3.45 kg
With 80
o
stands
Dimensions (WkHkD)
950 mmk118 mmk80 mm
Mass 3.47
kg
Operating temperature range
0
o
C to i40
o
C
Operating humidity range
20 % to 80 % RH (no condensation)
Bluetooth
®
SECTION
Bluetooth
®
system specification
Version 3.0
Wireless equipment classification
Class 2
Supported profiles A2DP
Frequency band 2400 MHz to 2483.5 MHz
(Adaptive Frequency Hopping)
Operating distance 10 m Line of Sight
SC-HTB170EGEBGN_RQT9772-B.book 30 ページ ２０１３年２月４日 月曜日 午前９時５分

Panasonic SC-HTB170 Specifications

General

Audio decoders	Dolby Digital, Dolby Pro Logic II, DTS
RMS rated power	120 W
Audio output channels	2.1 channels
Audio Return Channel (ARC)	Yes
Impedance	6 Ω
Woofer diameter	80 mm
Number of woofer drivers	2
Soundbar speaker RMS power	60 W
Total Harmonic Distortion (THD)	10 %
Subwoofer type	Active subwoofer
Receiver included	No
Number of products included	1 pc(s)
Product color	Black
Recommended usage	TV
Consumer Electronics Control (CEC)	VIERA Link
Apple docking compatibility	Not supported
Soundbar dimensions (WxDxH)	950 x 105 x 66 mm
Connectivity technology	Wired
Digital audio optical in	1
Power source	AC
AC input voltage	220-240 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W
Power consumption (typical)	22 W

Weight and Dimensions

Soundbar weight	3400 g
