Panasonic SC-HTB170 - Remote Control; Battery Replacement; Operation Range

8
RQT9772
1 Turn the main unit on or off (> 20)
2 Adjust the dialog effect level (> 20)
3 Adjust the output level of the subwoofer
(bass sound) (> 20)
4 Adjust the volume of this system (> 20)
5 Mute the sound (> 20)
6 Select the input source (> 20)
“TV”--------------------#“BD/DVD”
^------------ “”(---------}
7 Select the Bluetooth
®
device as the source
(> 20)
8 Select the sound mode (> 21)
“STANDARD” -----#“STADIUM” ----#“MUSIC”
^- “STEREO”( “NEWS”( “CINEMA”(}
Remote control
SOUND
1
6
7
2
3
4
5
8
INPUT
SELECTOR
∫ Before using for the first time
Remove the insulation sheet A.
∫ To replace a button-type battery
Battery type: CR2025 (Lithium battery)
≥ Set the button-type battery with its (i) mark
facing upward.
≥ Keep the button-type battery out of reach of
children to prevent swallowing.


∫ Remote control operation range
The remote control signal sensor is located on the main unit.
≥Use the remote control within the correct operation range.

B Remote control signal sensor
≥ Operation range
Distance: Within approx. 7 m
directly in front
Angle: Approx. 30
o
left and right
