Panasonic TH-42PX60U - Page 181

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
R9527,2
8
EXB2HV272JV RESISTOR ARRAY 2
R9529,3
0
ERJ3GEYJ103 M 10KOHM,J,1/16W 2
R9531-
33
ERJ3GEYJ470 M 47 OHM,J,1/16W 3
R9534 EXB38V470J RESISTOR ARRAY 1
R9535,3
6
ERJ3GEYJ470 M 47 OHM,J,1/16W 2
R9538 ERJ3GEYJ103 M 10KOHM,J,1/16W 1
R9540 ERJ3GEYJ103 M 10KOHM,J,1/16W 1
R9543,4
4
ERJ3GEYJ103 M 10KOHM,J,1/16W 2
R9545 ERJ3GEYJ304V M 300KOHM,J,1/16W 1
R9548-
50
ERJ3GEYJ103 M 10KOHM,J,1/16W 3
R9552 ERJ3GEYJ103 M 10KOHM,J,1/16W 1
R9555 ERJ3GEY0R00 M 0 OHM, 1/16W 1
R9800 ERJ3EKF1302 M 23KOHM, 1/16W 1
R9801 ERJ3EKF2402 M 24KOHM, 1/16W 1
R9802 ERJ3EKF6202 M 62KOHM, 1/16W 1
R9803 ERJ3GEY0R00 M 0 OHM, 1/16W 1
R9804 ERJ3EKF2402 M 24KOHM, 1/16W 1
R9805 ERJ3EKF3002 M 30KOHM, 1/16W 1
R9806 ERJ3EKF3902 M 39KOHM, 1/16W 1
R9807 ERJ3GEY0R00 M 0 OHM, 1/16W 1
R9808 ERJ3GEYJ104 M 100KOHM,J,1/16W 1
R9810 ERJ3EKF3001 M 3KOHM, 1/16W 1
R9813 ERJ3EKF2401 M 2.4KOHM, 1/16W 1
R9814 ERJ3EKF6802 M 68KOHM, 1/16W 1
R9815 ERJ3EKF2202 M 22KOHM, 1/16W 1
R9816 ERJ3EKF8202 M 82KOHM, 1/16W 1
R9821 ERJ3GEYJ103 M 10KOHM,J,1/16W 1
R9823-
27
ERJ3GEYJ101 M 100 OHM,J,1/16W 5
R9828 ERJ3GEYJ104 M 100KOHM,J,1/16W 1
R9830,3
1
ERJ3GEYJ103 M 10KOHM,J,1/16W 2
R9838,3
9
ERJ3GEYJ101 M 100 OHM,J,1/16W 2
R9840 ERJ3GEYJ220 M 22 OHM,J,1/16W 1
R9841 ERJ3GEY0R00 M 0 OHM, 1/16W 1
R9842-
44
ERJ3GEYJ101 M 100 OHM,J,1/16W 3
R9845 ERJ3GEYJ562 M 5.6KOHM,J,1/16W 1
R9846,4
7
EXB2HV272JV RESISTOR ARRAY 2
R9848,4
9
EXB2HV470JV RESISTOR ARRAY 2
R9850 ERJ3GEYJ473 M 47KOHM,J,1/16W 1
R9854 ERJ3GEYJ101 M 100 OHM,J,1/16W 1
R9859 EXB38V101J RESISTOR ARRAY 1
R9861-
63
ERJ3GEYJ103 M 10KOHM,J,1/16W 3
R9868 ERJ3GEYJ104 M 100KOHM,J,1/16W 1
R9869-
71
ERJ3GEYJ103 M 10KOHM,J,1/16W 3
R9872 ERJ3GEY0R00 M 0 OHM, 1/16W 1
R9878 ERJ3EKF3902 M 39KOHM, 1/16W 1
R9879 ERJ3EKF2002 M 20KOHM, 1/16W 1
R9880 ERJ3EKF3602 M 36KOHM, 1/16W 1
R9883 ERJ3GEY0R00 M 0 OHM, 1/16W 1
R9884 ERJ3GEYJ104 M 100KOHM,J,1/16W 1
R9891 ERJ3EKF4702 M 47KOHM, 1/16W 1
R9892 ERJ3EKF1502 M 15KOHM, 1/16W 1
R9893 ERJ3EKF3602 M 36KOHM, 1/16W 1
R9896 ERJ3GEY0R00 M 0 OHM, 1/16W 1
R9897 ERJ3GEYJ104 M 100KOHM,J,1/16W 1
R9903 EXB2HV470JV RESISTOR ARRAY 1
R9904 ERJ3GEYJ470 M 47 OHM,J,1/16W 1
R9905 ERJ3GEYJ330 M 33 OHM,J,1/16W 1
R9906 EXB38V470J RESISTOR ARRAY 1
R9907 ERJ3GEYJ151 M 150 OHM,J,1/16W 1
R9917,1
8
ERJ3GEY0R00 M 0 OHM, 1/16W 2
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
R9919,2
0
ERJ3GEYJ103 M 10KOHM,J,1/16W 2
R9922 ERJ3GEY0R00 M 0 OHM, 1/16W 1
R9929 ERJ3GEY0R00 M 0 OHM, 1/16W 1
R9936-
39
ERJ3EKF1001 M 1KOHM, 1/16W 4
R9940 ERJ3GEYJ330 M 33 OHM,J,1/16W 1
R9941,4
2
ERJ3GEYJ470 M 47 OHM,J,1/16W 2
R9943-
51
EXB38V470J RESISTOR ARRAY 9
R9952-
55
ERJ3GEYJ470 M 47 OHM,J,1/16W 4
R9956 ERJ3GEYJ103 M 10KOHM,J,1/16W 1
RL402,0
3
TSEH8011 RELAY 2
RM2501 PNA4701M05TV REMOTE RECEIVER 1
RTL TNAG167S CIRCUIT BOARD DT 1 PAVCA
RTL TNPA3769S CIRCUIT BOARD H 1 PAVCA
RTL TNPA3855S CIRCUIT BOARD HC 1 PAVCA
RTL TNPA3903BAS CIRCUIT BOARD DG 1 PAVCA
RTL TXNPA1BJTUJ CIRCUIT BOARD PA 1 PAVCA
RTL TXNC11BKTUJ CIRCUIT BOARD C1 1 PAVCA
RTL TXNC21BKTUJ CIRCUIT BOARD C2 1 PAVCA
RTL TNPA3810AFS CIRCUIT BOARD D 1 PAVCA
RTL TXN/P1BKTU CIRCUIT BOARD P 1 PAVCA
RTL TXNSC1BKTUJ CIRCUIT BOARD SC 1 PAVCA
RTL TXNSD1BKTUJ CIRCUIT BOARD SD 1 PAVCA
RTL TXNSS1BKTUJ CIRCUIT BOARD SS 1 PAVCA
RTL TXNSU1BKTUJ CIRCUIT BOARD SU 1 PAVCA
RTL TNPA3764ADS CIRCUIT BOARD G 1 PAVCA
RTL TNPA3965ACS CIRCUIT BOARD GK 1 PAVCA
RTL TNPA3853ABS CIRCUIT BOARD GS 1 PAVCA
RTL TNPA3762AGS CIRCUIT BOARD K 1 PAVCA
RTL TNPA3964ABS CIRCUIT BOARD S 1 PAVCA
S2 K1KA02BA0061 2P CONNECTOR 1
S401,02 J0LT00000009 SWITCH 2
SC2 K1KA02A00626 2P CONNECTOR 1
SC20 K1KA20AA0008 20P CONNECTOR 1
SC23 K1KA03AA0193 3P CONNECTOR 1
SC30 K1KA08AA0192 8P CONNECTOR 1
SC41,42 K1ML80B00001 80P CONNECTOR 2
SC45,46 K1KA09A00239 9P CONNECTOR 2
SD1-D3 K1MNC0B00002 CONNECTOR 3 PAVCA
SD46 K1KB09A00045 9P CONNECTOR 1
SS11 K1KA02A00626 2P CONNECTOR 1
SS12 K1KA10AA0194 10P CONNECTOR 1
SS23 K1KA12AA0194 12P CONNECTOR 1
SS34 K1KA03AA0193 3P CONNECTOR 1
SS41A-
4A
K1MN13B00020 13P CONNECTOR 4
SU1-U3 K1MNC0B00002 CONNECTOR 3 PAVCA
SU45 K1KB09A00045 9P CONNECTOR 1
SW2500 K0F122A00172 POWER SWITCH 1
SW3754-
58
EVQ11G05R SWITCH 5
T401 G4D4A0000119 SWITCHING
TRANSFORMER
1
T402 G4D1A0000098 SWITCHING
TRANSFORMER
1
T404 ETS42LA12GAD SWITCHING TRANS 1
T407 ETQ11K5AZ CHOKE TRANS 1
T410 ETS25AF115AH SWITCHING TRANS 1
T601 G4D2A0000264 SWITCHING TRANS 1
T6602 ETS25AZ139AD SWITCHING TRANS 1
181
TH-37PX60U / TH-42PX60U
